Quick Details
-
Max. Wheel Weight:
-
65Kg
-
Place of Origin:
-
Liaoning, China
-
Brand Name:
-
Jaray
-
Model Number:
-
F-650
-
Warranty:
-
18 Months
-
Product Name:
-
Wheel Balancer
-
Color:
-
Blue/ Red
-
Certification:
-
CE
-
Measuring time:
-
6-8s
-
Packing Size:
-
1000mm*680mm*1060mm
-
Year:
-
Other
-
Car Fitment:
-
Other
-
Model:
-
Other
Quick Details
-
Power:
-
0.25Kw
-
Power Supply:
-
220v
-
Balancing Speed:
-
200turn
-
Max. Wheel Weight:
-
65Kg
-
Place of Origin:
-
Liaoning, China
-
Brand Name:
-
Jaray
-
Model Number:
-
F-650
-
Warranty:
-
18 Months
-
Product Name:
-
Wheel Balancer
-
Color:
-
Blue/ Red
-
Certification:
-
CE
-
Measuring time:
-
6-8s
-
Packing Size:
-
1000mm*680mm*1060mm
-
Year:
-
Other
-
Car Fitment:
-
Other
-
Model:
-
Other
Product introduction
|
Product name
|
Medium wheel balancer
|
Product model
|
F-650
|
|
Motor voltage
|
220v
|
Motor power
|
0.25kw
|
|
Max.wheel diameter
|
1000mm
|
Maxi.wheel weight
|
65kg
|
|
Measuring time
|
6-8s
|
Balancing accuracy
|
±1g
|
|
Rim width
|
1.5-16
|
Rim diameter
|
13-24
|
|
Spindle speed
|
≤200r/min
|
Gross weight
|
110kg
|
|
Equipment size
|
1070mm×580mm×1290mm
|
Packing dimensions
|
1000mm×680mm×1060mm
|
The display board of wheel balancer is set independently, easy to operate and suitable for angle.
Wheel alancing Machine adopts Precision Spindle with Low Speed Bearing
.Phosphating treatment of spindle, anti-corrosion and anti-rust
Wheel balancing Machine Professional Motor Passed CE Certification
, the noise of pure copper core is low, and the heat dissipation performance of aluminium alloy end cover is stronger, which can avoid the motor temperature caused by frequent starting or braking.
Compound welded box, internal structure with "U" groove reinforcement welding, to ensure the stability of the chassis, and can withstand a larger weight of tires.
The top cover of injection moulding process ensures beauty and strength, and the multi-station toolbox facilitates the classification of balance blocks.
Random Accessories
Packing box style
Product introduction
|
Product name
|
Right helper arm backward tire changer
|
Product model
|
F-596
|
|
Outer Clamp
|
10-20
|
Inter Clamp
|
12-24
|
|
Max.Wheel Width
|
345mm
|
Max.Wheel Diameter
|
1040mm
|
|
Motor voltage
|
220v/380v
|
Motor power
|
1.1kw/0.75kw
|
|
Working noise
|
<70db
|
Operating air pressure
|
8-10bar
|
|
Net weight
|
270kg
|
Gross weight
|
320kg
|
|
Equipment size
|
1100mm×900mm×1820mm
|
Packing dimensions
|
1180mm×920mm×1770mm
|
Main Features
The pneumatic locking push-pull arm is used in this tire changer. The column can be tilted backward. The working space for installing and disassembling tires is increased.
Main Features
The 24-inch working disc is 630 mm in diameter and 14.5 mm in thickness.tire changer rotective sheets are installed under the fixed claws and the metal joints of the whole machine are installed.
Main Features
The back end of the woking shovel support is lengthened, so that the force angle of the shovel is better and the storage box is super large.Thicken the rubber pad of the shovel, increase the service life, rotate the shovel from multiple angles, and fit the tire better.
Main Features
A.Cylinder
B.Box reinforcement support
C.Engine
D.Turbine box
E.Back-up Column Cylinder
Random Accessories
Packing box style
