Quick Details
-
Model Number:
-
W-102B&W-181B
-
Dimension:
-
544*245*375mm
-
Storage:
-
Other
-
SNR:
-
Other
-
Output Power:
-
350W(RMS)1400W(PEAK)
-
Format:
-
line array system
-
Type:
-
line array system
-
Frequency Response:
-
70Hz-20KHz±3dB / 35Hz-300Hz±3dB
-
Color:
-
Black
-
Nominal impedance:
-
8 ohm
-
Coverage:
-
110°H*10°V
-
Finsh:
-
Textured high-density polyurethane coating
-
Sensitivity:
-
100dB(1W@1M) / 103dB(1W@1M)
-
Max SPL:
-
125dB(PEAK/1M) / 132dB(PEAK/1M)
-
Connectors:
-
2*NL4MP speakon
-
Enclosure Material:
-
Birch Plywood
Quick Details
-
Warranty:
-
1year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CVR
-
Model Number:
-
W-102B&W-181B
-
Dimension:
-
544*245*375mm
-
Storage:
-
Other
-
SNR:
-
Other
-
Output Power:
-
350W(RMS)1400W(PEAK)
-
Format:
-
line array system
-
Type:
-
line array system
-
Frequency Response:
-
70Hz-20KHz±3dB / 35Hz-300Hz±3dB
-
Color:
-
Black
-
Nominal impedance:
-
8 ohm
-
Coverage:
-
110°H*10°V
-
Finsh:
-
Textured high-density polyurethane coating
-
Sensitivity:
-
100dB(1W@1M) / 103dB(1W@1M)
-
Max SPL:
-
125dB(PEAK/1M) / 132dB(PEAK/1M)
-
Connectors:
-
2*NL4MP speakon
-
Enclosure Material:
-
Birch Plywood
Product Description
|
Model
|
W-102&W102P
W-181B&W-181BP
|
|
Type
|
Two-way line array system
Line array subwoofer system(W-181D)
|
|
Frequency Response
|
70Hz-20KHz±3dB
40Hz-500Hz±3dB(W-181D)
|
|
Power handling
|
LF 350W(RMS)1400W(PEAK) HF 100W(RMS)400W(PEAK)
|
|
|
1000W(RMS)4000W(PEAK)(W-181D)
|
|
Sensitivity
|
LF 100dB(PEAK/1M) HF 102dB(PEAK/1M)
|
|
|
103dB(1W/1M)(W-181D)
|
|
Max SPL
|
LF 125dB(PEAK/1M) HF 129dB(PEAK/1M)
|
|
|
132dB(1W/1M)(W-181D)
|
|
Drivers
|
LF 1×10"(260mm)neodymium woofer 65mm(2.5in)coil
|
|
|
HF 1×2.5" neodymium compression driver with 65mm titanium diaphragm
|
|
|
1×18"(460mm)woofer with 100mm (4in) coil(W-181D)
|
|
Nominal impedance
|
8 ohm
|
|
Coverage
|
110º H×10º V
|
|
Connectors
|
2×NL4MP speakon
|
|
Finish
|
Textured high-density polyurethane coating
|
|
Enclosure Material
|
HDPE Birch Plywood
|
|
Dimensions
|
560×245×375mm(W×H×D)
|
|
|
561×776×680mm(W×H×D)(W-181D)
|
|
Packing Dimensions
|
640×370×490mm(W×H×D)/0.115cbm
|
|
|
645×830×765mm(W×H×D)/0.41cbm(W-181D)
|
|
Net weight
|
15kg(W-102)/16kg(W-102P)
|
|
|
40.5kg(W-181D)/42kg(W-181DP)
|
|
Gross weight
|
18.5kg(W-102)/19.5kg(W-102P)
|
|
|
44.5kg(W-181D)/46kg(W-181DP)
|
