Quick Details
-
Color:
-
full color
-
Panel Size:
-
500*500, 500*500
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
3.91-500*500
-
Brightness:
-
4000-6000, 4000-6000
-
pixel density:
-
128*128, 128*128
-
Color Depth:
-
RGB, RGB
-
Lifespan (hours):
-
100000, 100000
-
IP Rating:
-
65, 65
-
Resolution:
-
128*128
-
View Angle（H/V）:
-
120/140, 120/140
-
application:
-
Outdoor
-
Cabinet Size(mm):
-
500*500 or 500*1000
-
Refresh Rate:
-
1920-3840 Hz
-
Display Function:
-
video
-
delivery time:
-
10 to 20 days
-
Screen Dimension:
-
Customized
-
Cabinet material:
-
die-casting aluminum
-
Grey scale:
-
14-16 bit
-
Product name:
-
rental display
Quick Details
-
Application:
-
Indoor, Outdoor
-
Type:
-
LED
-
Brand Name:
-
CHUANGYI
-
Color:
-
full color
-
Panel Size:
-
500*500, 500*500
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
3.91-500*500
-
Brightness:
-
4000-6000, 4000-6000
-
pixel density:
-
128*128, 128*128
-
Color Depth:
-
RGB, RGB
-
Lifespan (hours):
-
100000, 100000
-
IP Rating:
-
65, 65
-
Resolution:
-
128*128
-
View Angle（H/V）:
-
120/140, 120/140
-
application:
-
Outdoor
-
Cabinet Size(mm):
-
500*500 or 500*1000
-
Refresh Rate:
-
1920-3840 Hz
-
Display Function:
-
video
-
delivery time:
-
10 to 20 days
-
Screen Dimension:
-
Customized
-
Cabinet material:
-
die-casting aluminum
-
Grey scale:
-
14-16 bit
-
Product name:
-
rental display
Product Specification
|
Pixel Pitch(mm)
|
2.604mm
|
2.976mm
|
3.91mm
|
4.81mm
|
|||
|
LED Type
|
SMD1415
|
SMD1415
|
SMD1921
|
SMD1921
|
|||
|
application scenarios
|
Outdoor
|
Outdoor
|
Outdoor
|
Outdoor
|
|||
|
Pixel Density(dot/㎡)
|
147456dots
|
112896 dots
|
65536 dots
|
43264 dots
|
|||
|
Module Size/mm
|
250x250
|
250x250
|
250x250
|
250x250
|
|||
|
Module Resolution
|
96X96 dots
|
84x84 dots
|
64x64 dots
|
52x52 tots
|
|||
|
Scan
|
1/32S
|
1/28S
|
1/16S
|
1/13S
|
|||
|
Cabinet Size/mm
|
500X500mm
|
500X500mm 500X1000mm
|
500X500mm 500X1000mm
|
500X500mm 500X1000mm
|
|||
|
Cabinet Resolution
|
192x192 dots
|
168x168 dots 168x336 dots
|
128x128 dots 128x256 dots
|
104x104 dots 104x208 dots
|
|||
|
Cabinet weight
|
8.5KG
|
8.5KG
14KG
|
8.5KG
14KG
|
8.5KG
14KG
|
|||
|
IP protection
|
IP65
|
IP65
|
IP65
|
IP65
|
|||
|
Brightnes（cd/m²）
|
≥4000-6000 nit
|
≥4000-6000 nit
|
≥4000-6000 nit
|
≥4000-6000 nit
|
|||
|
View Angle/°
|
160°/ 140°(H/V)
|
160°/ 140°(H/V)
|
160°/ 140°(H/V)
|
160°/ 140°(H/V)
|
|||
|
Gray Scale/bit
|
14-16 bit
|
14-16 bit
|
14-16 bit
|
14-16 bit
|
|||
|
Max power(w/m²)
|
800 W/m²
|
800 W/m²
|
800 W/m²
|
800 W/m²
|
|||
|
Averagepower(w/m²)
|
240 W/m²
|
240 W/m²
|
240 W/m²
|
240 W/m²
|
|||
|
Refresh Frequency/Hz
|
3840 HZ
|
1920/3840 HZ
|
1920/3840 HZ
|
1920/3840 HZ
|
|||
|
Operating Voltage
|
AC 96~242V 50/61Hz
|
|
|
|
|||
|
Operating Temperature
|
-20~45°C
|
|
|
|
|||
|
Operating Humidity
|
10~90%RH
|
|
|
|
|||
|
Operating Life
|
100,000 Hours
|
|
|
|
|||
