Quick Details
-
Brand Name:
-
KATU
-
Model Number:
-
PC300
-
Max. Working Pressure:
-
230V
-
IP level:
-
IP65
-
Measuring medium::
-
liquid or gas
-
Pressure adjustment range::
-
see technical parameters for details
-
Repeatability::
-
≤±3% (related to the set value)
-
Certification:
-
CE
Quick Details
-
Whether the smart:
-
Yes
-
Max. Voltage:
-
230V
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
KATU
-
Model Number:
-
PC300
-
Max. Working Pressure:
-
230V
-
IP level:
-
IP65
-
Measuring medium::
-
liquid or gas
-
Pressure adjustment range::
-
see technical parameters for details
-
Repeatability::
-
≤±3% (related to the set value)
-
Certification:
-
CE
|
Measuring medium:
|
liquid or gas
|
|
Pressure adjustment range:
|
see technical parameters for details
|
|
Repeatability:
|
≤±3% (related to the set value)
|
|
Output method:
|
gold-plated contact micro switch SPDT (Normally Open + Normally Closed)
|
|
Switching capacity
|
No signal light: 30VDC, 2A 250VAC, 3A
With signal light: 24-250V, 0.6A
|
|
Adjustment method:
|
hexagon socket head screw
|
|
Switching action frequency:
|
MAX.100 times/min
|
|
Ambient temperature:
|
-20...85℃
|
|
Medium temperature:
|
-20...80℃
|
|
Material
|
Housing: Steel
Wetted material: NBR, aluminum/steel/stainless steel
Process connection: aluminum/steel/stainless steel optional
|
|
Outlet method:
|
solenoid valve connector
|
Details Images
size
