Quick Details
-
Brand Name:
-
Hualiang
-
Model Number:
-
VHF-060-012A2
-
Output Frequency:
-
50Hz/60Hz
-
Product Name:
-
power supply 12v 60w
-
Shell material:
-
aluminum
-
Dimenssion:
-
222*30*20(mm)
-
IP Rate:
-
IP67
-
Efficiency:
-
87%
-
PFC:
-
≥0.9
-
Application:
-
led strip/led lamp/led light/mirror light
-
Certificate:
-
CE CB ROSH SAA ETL CCC UKCA ERP BIS
-
Customized service:
-
OEM/ODM label cable plug
-
Delivery:
-
DHL,UPS,FEDEX,TNT,by air and by sea
Quick Details
-
Warranty(Year):
-
3-Year
-
Product Weight（kg）:
-
0.3
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Hualiang
-
Model Number:
-
VHF-060-012A2
-
Output Frequency:
-
50Hz/60Hz
-
Product Name:
-
power supply 12v 60w
-
Shell material:
-
aluminum
-
Dimenssion:
-
222*30*20(mm)
-
IP Rate:
-
IP67
-
Efficiency:
-
87%
-
PFC:
-
≥0.9
-
Application:
-
led strip/led lamp/led light/mirror light
-
Certificate:
-
CE CB ROSH SAA ETL CCC UKCA ERP BIS
-
Customized service:
-
OEM/ODM label cable plug
-
Delivery:
-
DHL,UPS,FEDEX,TNT,by air and by sea
Specifications:
|
Model |
VHF-060-012A2 | VHF-060-024A2 | |
| Output | DC VOLTAGE | 12V | 24V |
| RATED CURRENT | 5A | 2.5A | |
| CURRENT RANGE | 0~5A | 0~2.5A | |
| RATED POWER | 60W | ||
| RIPPLE&NOISE(max) | <1.9V | <1.9V | |
| VOLTAGE TOLERANCE | ±0.5V | ±0.5V | |
| Input | VOLTAGE RANGE | 170~265VAC | |
| FREQUENCY RANGE | 47~63Hz | ||
| POWER FACTOR(Full load) | ≥0.9 | ||
| EFFICIENCY(Typ.) | 87% | 88% | |
| AC CURRENT(Typ.) | 0.4A/220VAC | 0.4 A/220VAC | |
| Protection | Short circuit | Protection type:Hiccpe mode,recovers automatically after condition is removed | |
| Overload | 7A | 3.5A | |
| Environment | WORKING TEMP. | -30~+50℃ (Please Refer to output load derating curve) | |
| WORKING HUMIDITY | 20 ~ 95% RH non-condensing | ||
| INGRESS PROTECTION | IP67 design for indoor or outdoor installations | ||
| STORAGE TEMP., HUMIDITY | -40 ~ +80 , 10 ~ 95% RH | ||
| Safety | Safety standards | Suitable for EN61347-1;EN61347-2-13;SELV;IP67 | |
| WITHSTAND VOLTAGE | I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC | ||
| ISOLATION RESISTANCE | I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH | ||
| EMC |
EN55015,EN61000-3-2,EN61000-3-3
EN61547 |
||
| Note |
1.All parameters NOT specially mentioned are measured at 220VAC input,rated load and 25℃ of ambient temperature. 2.Ripple&noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf&47uf parallel capacitor. 3.Tolerance:includes set up tolerance,line regulation and load regulation. |
||
-
Why choose us?
* All products complete CE ,SAA, RoHS,ERP approval, some products have got ETL ,TUV, GS, CB,BIS certificates.
* Made by our own factory, for control the quality also for the LED Driver is stable and reliable.
* Focus on the LED Driver research and development, production more than 13years.
* All products are widely used in Domestic government projects not only, but also Office space, Shopping malls, Star hotel, home lights etc. In all over the world.
* OEM , ODM are all welcome, unchanged quality and competitive price.
