Quick Details
-
Warranty:
-
1 Year, 12 Months/1000 Hours
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Wellpower
-
Model Number:
-
WP-YD18GF
-
Prime Power:
-
18 KW
-
Standby Power:
-
20 KW
-
Bore*Stroke:
-
85mm*95mm
-
Aspiration Type:
-
Natural
-
Engine model:
-
YND485ZLD
-
CYL:
-
4
-
Displacement:
-
2.156
-
Lube:
-
6 L
-
Dimension:
-
2000*730*1130mm
Quick Details
-
Rated Voltage:
-
220V, 230V, 380v, 400V
-
Rated Current:
-
82 A
-
Frequency:
-
50Hz / 60Hz
-
Warranty:
-
1 Year, 12 Months/1000 Hours
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Wellpower
-
Model Number:
-
WP-YD18GF
-
Prime Power:
-
18 KW
-
Standby Power:
-
20 KW
-
Bore*Stroke:
-
85mm*95mm
-
Aspiration Type:
-
Natural
-
Engine model:
-
YND485ZLD
-
CYL:
-
4
-
Displacement:
-
2.156
-
Lube:
-
6 L
-
Dimension:
-
2000*730*1130mm
Technical Specification
|
Model |
Voltage |
HZ |
P.F (COS) |
Standby power |
Prime power |
Net Weight |
|
WP-YD18 GF |
220V-Single phase |
5 0 |
1 |
20 KW |
18 KW |
750 kg |
Prime power
This rating is for the supply of continuous electrical power (at variable load). There is no limit on the annual hours of operation and 10% overload power can be supplied for 1 hour in 12.
Standby power
This rating is for the supply of continuous electrical power (at variable load) in the event of a utility power failure. No overload is permitted.
General features:
n Every generator set is subjected to a comprehensive test program which includes 50% load, 75% load,100% load, 110% load and the checking and proving of all control and safety shut-down functions;
n 24V DC start motor;
n Equipped 24V high performance maintenance-free lead-acid starting batteries and connecting with cables;
n Equipped with industrial silencer and flexible exhaust hose;
n Designed to Comply with ISO8528/GB2820;
n Powered by YangDong engine, Wellpower alternator and DeepSea/ComAp/SmartGen control panel
Engine Spec
| Engine model |
YND485ZLD |
| Engine manufacturer |
YangDong |
| Number of Cylinders |
4 cylinders in line |
| Aspiration type | Natural |
|
Bore×Stroke |
85mm ×95mm |
| Displacement | 2.156 L |
| Compression ratio |
18 : 1 |
| Prime power | 24 KW |
| Standby power | 26 KW |
| Steady Speed droop |
≤ 1% |
|
Coolant capacity(engine only) |
3.5 L |
|
Fuel Consumption |
245 g/kw.h |
|
Starter Motor |
DC24V, |
|
Alternator |
DC24V |
Alternator Spec
| Alternator model | WP184E |
| Prime power |
18 KW |
| Standby power | 20 KW |
| Exciter type |
Single bearing, Brushless, Self-excited |
| Power factor | 0.8 |
|
Voltage adjust range |
≥ 5% |
|
Voltage regulation NL-FL |
≤± 1% |
|
Insulation Grade |
H |
|
Protection Grade |
IP23 |
|
Phase |
Three phases |
Control Panel
|
Model |
SmartGen/ComAp/Deepsea |
|
The control module gives digital readouts of: |
Generator voltage; Output frequency; Engine speed; Battery voltage; Engine hours run. |
|
The control module has indicators for failure information: |
Over speed / under speed, Emergency stop Low oil pressure; High water temperature Failure to start Battery charger failure |
|
Automatic shutdown occurs under: |
Low engine oil pressure; High engine water temperature; Over speed/ under speed; Failure to start after three attempts |
Standard Accessories
|
Open type |
Silent type |
|
|
Sound-proof & Weather-proof Canopy |
N/A |
√ |
|
Daily base fuel tank. 8 hours capacity |
N/A |
√ |
|
Single-bearing generator again drops |
√ |
√ |
|
Intelligent LED display control panel |
√ |
√ |
|
Speed governor |
√ |
√ |
|
Electric start and 24v charger |
√ |
√ |
|
Standard air filter, oil filter, fuel filter |
√ |
√ |
|
Cooling water tank |
√ |
√ |
|
High-efficient silencer. |
√ |
√ |
|
Exhaust elbow |
√ |
√ |
|
Storage battery |
√ |
√ |
|
Steel base-frame against vibration |
√ |
√ |
|
Soft pipe for fuel and handle for lube going-out |
√ |
√ |
|
Operation& Maintenance manual |
√ |
√ |
