Quick Details
-
Model Number:
-
RL1-111/N-C-2-RE/BK-P2-RS
-
Max. Current:
-
16A
-
Mechanical Life:
-
20000
-
Products Name:
-
Rocker Switch
-
Function:
-
ON-OFF SPST
-
Rating:
-
16A 250 VAC 15A 125VAC
-
Application:
-
Appliance
-
Electrical Life:
-
10000cycles
-
Led color:
-
Green\Blue\Red\Orange\White
-
Certification:
-
Optional
Quick Details
-
Max. Voltage:
-
250VAC
-
Place of Origin:
-
China
-
Brand Name:
-
RLEIL
-
Model Number:
-
RL1-111/N-C-2-RE/BK-P2-RS
-
Max. Current:
-
16A
-
Mechanical Life:
-
20000
-
Products Name:
-
Rocker Switch
-
Function:
-
ON-OFF SPST
-
Rating:
-
16A 250 VAC 15A 125VAC
-
Application:
-
Appliance
-
Electrical Life:
-
10000cycles
-
Led color:
-
Green\Blue\Red\Orange\White
-
Certification:
-
Optional
Product Description
|
Specifications
|
|
|
Rating Options
|
16(4)A 250VAC T125/55 1E4
15A 125V/7.5A 250VAC
|
|
Circuit
|
ON-OFF SPST
|
|
Contact Resistance
|
30mΩ Max
|
|
Insulation Resistance
|
DC 500V, 100MΩ Min
|
|
Dielectric Strength
|
AC 1500V for 1 minute
|
|
Electrical Life
|
10000 Cycles at full load
|
|
Operating Force
|
500~750gf
|
|
Operating Temperature
|
-25℃~125℃
|
Note:Specifications listed above are for switches with standard options. For more information on custom switches,please feel free to contact us.
