Quick Details
-
Model Number:
-
LB2822
-
Max. Current:
-
lth:20A
-
Mechanical Life:
-
200000 times
-
Diameter:
-
28*22mm
-
Switch Combination:
-
2NO/2NO2NC
-
Operation type:
-
Latching
-
Lamp color:
-
Red Green Yellow Blue White
-
Lamp voltage:
-
2V/3V/6V/12V/24V/36V/110V/220V/250V
-
Rated Voltage/Current:
-
AC250V/16A
-
Shell Metal:
-
PA66
-
Certification:
-
CCC,CE
Quick Details
-
Max. Voltage:
-
250VAC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LANBOO
-
Model Number:
-
LB2822
-
Max. Current:
-
lth:20A
-
Mechanical Life:
-
200000 times
-
Diameter:
-
28*22mm
-
Switch Combination:
-
2NO/2NO2NC
-
Operation type:
-
Latching
-
Lamp color:
-
Red Green Yellow Blue White
-
Lamp voltage:
-
2V/3V/6V/12V/24V/36V/110V/220V/250V
-
Rated Voltage/Current:
-
AC250V/16A
-
Shell Metal:
-
PA66
-
Certification:
-
CCC,CE
Product Description
| 1.Drawing process, Aluminum oxidation of key |
| 2.Beautiful shape, Matching hand |
| 3.Metal frame, Waterproof fireproof IP65 |
| 4.High quality service, high-end products |
| 5.Independent research and development, patent products |
| 6.Rated current up to 16A 250VAC,4000W Resistive load |
Specification
| Model Description | |
| Model NO. | LB2822-rocker switch |
| Mounting diameter | 28*22mm |
| Mounting thickness | ≤3.5mm |
| Contact resistance | ≤50MΩ |
| Dielectric Strength | 3000VAC,50HZ,1min |
| Rated load | 16A 250VAC,16A24VDC |
| Electrical Life |
AC250V/20A, DC36V/20A: 10,000 times; AC250V/8A, DC36V/8A: 40,000 times; AC250V/3A, DC36V/3A: 100,000 times |
| Mechanical life | 200,000 times |
| Degree of Protection | IP65 |
| LED rated load | DC3-8V,9-24V,25-48V |
| Illuminated LED color | Red,Green,Blue,Yellow,White |
