Quick Details
-
Dimension(L*W*H):
-
660mm*740mm*760mm
-
Weight (KG):
-
35
-
Type:
-
Filling Machine
-
Filling Material:
-
Water
-
Machinery Test Report:
-
Provided
-
Core Components:
-
Pressure vessel
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Online support, Video technical support, Free spare parts, Field installation, commissioning and training
-
Production Capacity:
-
25-30pcs/min
-
Filling Amount:
-
Adjustable 1.1g±0.2g
-
Filling Error:
-
±0.05g
-
Function:
-
Liquid Filling Sealing
-
Local Service Location:
-
None
-
After Warranty Service:
-
Video technical support, Online support, Spare parts, Field maintenance and repair service
-
Certification:
-
CE/ISO9001
Quick Details
-
Voltage:
-
220V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
MIZIHO
-
Dimension(L*W*H):
-
660mm*740mm*760mm
-
Weight (KG):
-
35
-
Type:
-
Filling Machine
-
Filling Material:
-
Water
-
Machinery Test Report:
-
Provided
-
Core Components:
-
Pressure vessel
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Online support, Video technical support, Free spare parts, Field installation, commissioning and training
-
Production Capacity:
-
25-30pcs/min
-
Filling Amount:
-
Adjustable 1.1g±0.2g
-
Filling Error:
-
±0.05g
-
Function:
-
Liquid Filling Sealing
-
Local Service Location:
-
None
-
After Warranty Service:
-
Video technical support, Online support, Spare parts, Field maintenance and repair service
-
Certification:
-
CE/ISO9001
MIZIHO Machinery RYO-MINI-III Tobacco Filling Machine
Feature and advantage
1. This honey filling machine uses imported mechanical components, Taiwan passenger cylinder, the piston uses ptfeEne, the cylinder travel of 500,000 kilometers;
2. This honey filling machine has a unique design. Firstly, the solid method is adopted to ensure that it is absolutely ahead of similar products. The measuring accuracy can be controlled within 0.5%.
3. T he new design, light and convenient, can automatically draw the material (liquid), exempt from hopper frequent charging trouble;
4. M anual and automatic switch to each other, as well as artificial foot filling, but also mechanical automatic flling; Material cylinder, tee part adopts fast connection, convenient disassembly, convenient cleaning,compely with GMP standard,
5. W hen filling the cylinder moves up and down, drive straight, straight down, down the cylinder Cylinder up,straight up, not noly, wire drawing;
Technical parameters
|
Name |
Semi automatic honey filling machine |
|
Model |
MZH-F 50 - 500ML |
|
Article |
Liquid or paste |
|
Volume |
5-60ml 10-120ml 25ml-250ml 50-500ml 100-1000ml 250-2500ml 500-5000ml |
|
Filling |
Piston pump |
|
Precision |
±0.5% |
|
Pneumatic |
0.2-0.6Mpa |
|
Caliber |
≥5mm |
|
Capacity |
20- 3 0 times/min |
|
G.W. |
75Kg. |
|
Dimension |
L1550*W450*H550mm |
|
Function |
M ZH 50-500ml S emi-automatic honey filling machine, suitable for liquid, cigarette, shampoo, face cream and other liquid products. Simple design and convenient operation; It can be filled with various liquids, creams, such as shampoo, lotion, skin care, honey, shower, body cream and so on. |
|
Remarks |
M ZH-F 50-500ml S emi-automatic honey filling machine is suitable for automatic or manual filling of gels, emulsions and olive oil. If you want automatic filling, you should adjust the filling grams.When it fills at the appropriate grams then fills. The speed can be adjusted. If manual filling is required, press the pedal of the machine.Once is enough. |
