Quick Details
-
Spindle Taper:
-
MT3
-
Range of Spindle Speed(r.p.m):
-
50 - 2500 r.p.m
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Sumore Machinery
-
Model Number:
-
SP2240
-
Table Travel (mm):
-
250/100
-
Voltage:
-
Customer Requirement
-
Dimension(L*W*H):
-
570x510x740mm
-
Weight (KG):
-
80
-
Drilling capacity:
-
16mm
-
Spindle Speed:
-
50-2500rpm
-
End milling capacity::
-
30mm
-
Face milling capacity::
-
13mm
-
Spindle stroke::
-
180mm
-
Longitudinal travel(X)::
-
250/300mm
-
Cross travel(Y)::
-
100/130mm
-
Spindle rotary angle::
-
-45~+45
-
Table effective size::
-
410/460*112mm
-
Power (kW):
-
0.55
Quick Details
-
Table Travel (X) (mm):
-
300 mm
-
Table Travel (Y) (mm):
-
130 mm
-
Table Travel (Z) (mm):
-
180 mm
-
Spindle Taper:
-
MT3
-
Range of Spindle Speed(r.p.m):
-
50 - 2500 r.p.m
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Sumore Machinery
-
Model Number:
-
SP2240
-
Table Travel (mm):
-
250/100
-
Voltage:
-
Customer Requirement
-
Dimension(L*W*H):
-
570x510x740mm
-
Weight (KG):
-
80
-
Drilling capacity:
-
16mm
-
Spindle Speed:
-
50-2500rpm
-
End milling capacity::
-
30mm
-
Face milling capacity::
-
13mm
-
Spindle stroke::
-
180mm
-
Longitudinal travel(X)::
-
250/300mm
-
Cross travel(Y)::
-
100/130mm
-
Spindle rotary angle::
-
-45~+45
-
Table effective size::
-
410/460*112mm
-
Power (kW):
-
0.55
home
Related Products
Product Description
- Robust Construction & Stable Performance
- Brushless Motor & Variable Spindle Speed
- Fine & Smooth Feeding Movement on Every Directions
- High Precision for Model Engineering
- Changable Table Length for Different Workpieces
- Optional Spindle Speed & Cutting Depth Digital Readout
- Optional Automatic Longitudinal Feeder
- Perfect for slotting, grooving, splines and gear cutting
| Model | SP2240 |
| Drilling Capacity | 16 mm |
| End Milling Capacity | 13 mm |
| Face Milling Capacity | 30 mm |
| Longitudinal Axis Travel (X) | 250 / 300 mm |
| Cross Axis Travel (Y) | 100 / 130 mm |
| Headstock Axis Travel (Z) | 180 mm |
| Effective Table Size | 410 / 460 x 112 mm |
| Spindle Taper | MT3 |
| Spindle Speed Range | 50 - 2,500 rpm |
| Motor Power | 550 W |
| Voltage and Frequency | Customrized |
| Net Weight | 62 kg |
| Packing Size (LxWxH) |
570 x 510 x 740 mm 640 x 565 x 720 mm |
| Gross Weight | 80 kg |
Accessories
| Standard Accessories | Optional Accessories |
| Drill Chuck | Automatic Worktable Feeder |
| Wrench Set | Spindle Speed Digital Readout |
| Toolbox and maintain tools | Cutting Depth Digital Readout |
| Oil Tray | Clamping Kit |
| Manual Instruction & Parts List | Mill Chuck |
| Milling Set | |
| Tapping Set | |
| Boring Set | |
| Swivel Worktable | |
| Vice | |
| Stand | |
| Work Light |
Packaging & Shipping
| Package |
1 set/polywood case
(aluminum strips strengthen)
|
| Minimum Order Quantity (MOQ) | 10 sets |
| Full Container Loading Quantity (FCL) |
108 sets/20’GP
(unitary; customerized packing available)
|
| Delivery Time | 20 calendar days after receiving of advance / full payment |
