Quick Details
-
Throat Depth (mm):
-
200 mm
-
Width of Working Table (mm):
-
1600 mm
-
Dimension:
-
2600*1700*2320
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Classic
-
Year:
-
2022
-
Weight (KG):
-
5000
-
Motor Power (kw):
-
5.5 kw
-
Marketing Type:
-
New Product 2022
-
Opening Height:
-
350mm
-
Raw Material:
-
Sheet Metal Plate
-
Name:
-
Hydraulic Cnc Press Brake
-
Product name:
-
Magnetic Bending Machine
-
Type:
-
Hydraulic Bending Tools
-
Function:
-
Steel Metal Bending
-
Keyword:
-
Bending Machine Metal Steel Sheet
-
Application:
-
Stainless Plate Bending
-
Table length:
-
2000/2500/3000/4000/5000mm
Quick Details
-
Machine Type:
-
Torsion Bar
-
Length of Working Table (mm):
-
2500
-
Slider Stroke (mm):
-
120 mm
-
Throat Depth (mm):
-
200 mm
-
Width of Working Table (mm):
-
1600 mm
-
Dimension:
-
2600*1700*2320
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Classic
-
Year:
-
2022
-
Weight (KG):
-
5000
-
Motor Power (kw):
-
5.5 kw
-
Marketing Type:
-
New Product 2022
-
Opening Height:
-
350mm
-
Raw Material:
-
Sheet Metal Plate
-
Name:
-
Hydraulic Cnc Press Brake
-
Product name:
-
Magnetic Bending Machine
-
Type:
-
Hydraulic Bending Tools
-
Function:
-
Steel Metal Bending
-
Keyword:
-
Bending Machine Metal Steel Sheet
-
Application:
-
Stainless Plate Bending
-
Table length:
-
2000/2500/3000/4000/5000mm
Product Description
Product description
1. The frame adopts whole welding structure, and by the fireplace tempering treatment, machine tool accuracy is good.
2. Hydraulic pressure type, step less pressure adjustment, using high quality imported sealing ring, to ensure the reliability of the machine tool.
3. Mechanical synchronization, using the upper and lower composite compensation structure, improve the machining accuracy of parts. (more than 160 tons for the working table compensation structure)
4. Adjust the slider stroke and adjust the position of the rear gear, use the electric quick adjustment and manual adjustment.
5. The machine tool is a little move, a single, continuous operation standard.
6. The machine tool is equipped with a safety protection bar and open door with power down device, which improves the safety ofoperation. (40 tons or more than 200 tons of no guard rails)
2. Hydraulic pressure type, step less pressure adjustment, using high quality imported sealing ring, to ensure the reliability of the machine tool.
3. Mechanical synchronization, using the upper and lower composite compensation structure, improve the machining accuracy of parts. (more than 160 tons for the working table compensation structure)
4. Adjust the slider stroke and adjust the position of the rear gear, use the electric quick adjustment and manual adjustment.
5. The machine tool is a little move, a single, continuous operation standard.
6. The machine tool is equipped with a safety protection bar and open door with power down device, which improves the safety ofoperation. (40 tons or more than 200 tons of no guard rails)
Product main technical specifications:
|
Hydraulic press brake (Series WC67Y/K)
|
|
|
|
|
|
|
|
|
|
|||||||||
|
Model
|
Pressure
(KN) |
Worktable length
(mm) |
Distance between columns (mm)
|
Depth of throat (mm)
|
Stroke
(mm) |
Max height between
worktable and ram (mm) |
Main motor (KW)
|
Weight
(KG) |
Dimension
(LxWxH) (mm) |
|||||||||
|
WC67Y/K-40/2500
|
400
|
2500
|
1925
|
220
|
80
|
300
|
4
|
3000
|
2650x1100x1950
|
|||||||||
|
WC67Y/K-50/2500
|
500
|
2500
|
2015
|
220
|
100
|
340
|
4
|
3750
|
2650x1250x2100
|
|||||||||
|
WC67Y/K-63/2500
|
630
|
2500
|
2015
|
250
|
100
|
340
|
5.5
|
4300
|
2650x1300x2200
|
|||||||||
|
WC67Y/K-80/2500
|
800
|
2500
|
2010
|
250
|
120
|
380
|
5.5
|
5200
|
2560x1350x2250
|
|||||||||
|
WC67Y/K-80/3200
|
800
|
3200
|
2510
|
250
|
120
|
380
|
5.5
|
6000
|
3260x1350x2280
|
|||||||||
|
WC67Y/K-100/2500
|
1000
|
2500
|
2050
|
320
|
150
|
420
|
7.5
|
6700
|
2550x1360x2270
|
|||||||||
|
WC67Y/K-100/3200
|
1000
|
3200
|
2550
|
320
|
150
|
420
|
7.5
|
7200
|
3260x1365x2520
|
|||||||||
|
WC67Y/K-100/4000
|
1000
|
4000
|
3050
|
320
|
150
|
420
|
7.5
|
8500
|
4060x1365x2720
|
|||||||||
|
WC67Y/K-125/3200
|
1250
|
3200
|
2550
|
320
|
150
|
420
|
7.5
|
7800
|
3260x1465x2600
|
|||||||||
|
WC67Y/K-125/4000
|
1250
|
4000
|
3050
|
320
|
150
|
420
|
7.5
|
9000
|
4060x1460x2800
|
|||||||||
|
WC67Y/K-160/3200
|
1600
|
3200
|
2590
|
320
|
200
|
475
|
11
|
10500
|
3260x1580x2775
|
|||||||||
|
WC67Y/K-160/4000
|
1600
|
4000
|
3040
|
320
|
200
|
475
|
11
|
12500
|
4060x1580x2925
|
|||||||||
|
WC67Y/K-160/6000
|
1600
|
6000
|
4800
|
320
|
200
|
480
|
11
|
19500
|
6060x1580x3480
|
|||||||||
|
WC67Y/K-200/3200
|
2000
|
3200
|
2580
|
320
|
200
|
475
|
18.5
|
13200
|
3260x1650x2800
|
|||||||||
|
WC67Y/K-250/4000
|
2500
|
4000
|
3130
|
400
|
250
|
530
|
18.5
|
19000
|
4060x1840x3150
|
|||||||||
|
WC67Y/K-250/5000
|
2500
|
5000
|
3930
|
400
|
250
|
530
|
18.5
|
24000
|
5060x1840x3450
|
|||||||||
|
WC67Y/K300/3200
|
3000
|
3200
|
2530
|
400
|
250
|
580
|
18.5
|
18000
|
3300x2100x2980
|
|||||||||
|
WC67Y/K-300/4000
|
3000
|
4000
|
3200
|
400
|
250
|
580
|
18.5
|
22000
|
4060x2040x3330
|
|||||||||
|
WC67Y/K-400/4000
|
4000
|
4000
|
3180
|
400
|
320
|
630
|
30
|
30000
|
4060x2220x3630
|
|||||||||
|
WC67Y/K-400/6000
|
4000
|
6000
|
4700
|
400
|
320
|
630
|
30
|
45000
|
60602x2203x980
|
|||||||||
|
WC67Y/K-500/6000
|
5000
|
6000
|
4600
|
500
|
320
|
70
|
30
|
55000
|
6080x2760x4000
|
|||||||||
|
WC67Y/K-800/6000
|
8000
|
6000
|
4600
|
500
|
400
|
900
|
37
|
72000
|
6100x3250x4300
|
|||||||||
Detailed Images
Recommend Products
Company Introduction
Packing&Shipping
FAQ
1. What is the payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;Irrevocable LC at sight .
When we receive the advance payment, we will start to make production.when the machine is ready , we will
take pictures to you.after we got your balance payment. we will send the machine to you.
2. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
3.How can I choose the most suitable machines ?
A: Please let us know your machining demand or machine size ,we can choose the best model for you ,
or you can choose the exact model by yourself. You can also send us the products drawing ,we will
choose the most suitable machines for you .
4. What is your trade terms?
A : FOB, CFR,CIF or others terms are all acceptable.
5. What is your minimum order quantity and warranty?
A: MOQ is one set, and warranty is one year.but we will offer lifetime service for machine.
6. What is the package of the machines?
A: The machines standard packed by iron pallets with plastic films
