Quick Details
-
Model Number:
-
SPK-Q5-160A4P
-
Rated Current:
-
400A
-
Type:
-
PC, I-O-II. Auto
-
Rated voltage:
-
AC 230V
-
Rated frequency:
-
50/60Hz
-
Conform standard:
-
ISO9001,3C
-
Operation type:
-
Manual or Auto
-
Indicator:
-
With Indicate light for Main power, and standby power.
Quick Details
-
Number of Pole:
-
4
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SPK
-
Model Number:
-
SPK-Q5-160A4P
-
Rated Current:
-
400A
-
Type:
-
PC, I-O-II. Auto
-
Rated voltage:
-
AC 230V
-
Rated frequency:
-
50/60Hz
-
Conform standard:
-
ISO9001,3C
-
Operation type:
-
Manual or Auto
-
Indicator:
-
With Indicate light for Main power, and standby power.
Product Description
Specification
|
Frame class
|
100
|
250
|
630
|
1600
|
3200
|
||||
|
Rated current In(A)
|
16-100
|
125-250
|
315-630
|
800-1600
|
2000-3200
|
||||
|
Rated insulation voltage(Ui)
|
690V
|
|
800V
|
|
|
||||
|
Rated concussion withstand voltage(Uimp)
|
8KV
|
|
|
|
|
||||
|
Rated working voltage(Ue)
|
AC400V
|
|
|
|
|
||||
|
Using category
|
AC-33B
|
|
|
AC-33iB
|
|
||||
|
Rated short-circuit connection capacity
|
8KA
|
17KA
|
26KA
|
67.5KA
|
|
||||
|
Rated short-time withstand current(lcw)
|
5kA/30ms
|
10kA/60ms
|
12.6kA/60ms
|
32kA/60ms
|
|
||||
|
Transfer time l-ll or ll-l
|
2.5s
|
0.6s
|
|
1.2s / 1.8s / 2.4s
|
|
||||
|
Control voltage
|
DC24V、48V、110V，AC220V
|
|
|
|
|
||||
|
Weight(kg) 4Pole
|
3.4kg
|
6-7.6kg
|
15.8-16.8kg
|
36-38.6kg
|
55-67kg
|
||||
Packing & Delivery
polyester film & carton
