Quick Details
-
Dimension(L*W*H):
-
2100*500*800MM
-
Weight (KG):
-
300 kg
-
Industrial Ultrasonic Cleaning Machine:
-
Industrial Cleaning Ultrasonic Agitation Degreasing
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Ultrasonic Agitation Degreasing
-
Power:
-
4KW
-
Dimension(L*W*H):
-
2100*500*800MM
-
Weight (KG):
-
300 kg
-
Industrial Ultrasonic Cleaning Machine:
-
Industrial Cleaning Ultrasonic Agitation Degreasing
Industrial Cleaning Ultrasonic Agitation Degreasing Machine
Industrial Cleaning Ultrasonic Agitation Degreasing Machine is single tank immersion cleaning equipped ultrasonic agitation and heating applied for hardware degreasing
Industrial Cleaning Ultrasonic Agitation Degreasing Machine
|
Industrial Cleaning Ultrasonic Agitation Degreasing Machine/ultrasonic cleaner |
||
|
Application |
||
|
used for cleaning metal parts with slim shape |
||
|
Character |
||
|
Auto frequency tracking function, which have advantage of automatic find the best ultrasonic performance for different cleaning parts This machine can connect with remote control |
||
|
Detailed parameter |
||
|
Name |
||
|
Model |
KLE-1080 |
|
|
Vibrators |
80pcs |
|
|
Auxiliary |
cleaning basket |
|
|
Ultrasonic power |
4KW |
|
|
Heating power |
12KW |
|
|
Vibrator standard |
28khz/40khz,50W/60w/pc (optional) |
|
|
Power supply |
380V/220V,50HZ/60HZ (optional) |
|
|
Size of inner cleaning tank |
2000*400*600mm(L*W*H) |
|
|
Size of outside |
2100*500*800mm |
|
|
Capacity |
480(only 400 is necessary) |
|
|
Control mode |
Mechanical |
|
|
Heating temperature |
0 up to 110 adjustable |
|
|
Vibration mode |
Bottom vibration |
|
|
Heating mode |
Heating board at two sides |
|
|
Cleaning basket |
Stainless steel, the mesh over 10*10mm |
|
|
Switch |
Separated Power Switch, Ultrasonic SW and Heating SW |
|
|
Configuration |
Assembled Four Universal wheel |
|
|
Separated lid/Cap |
||
|
With cleaning Basket |
||
|
Each generator has power wire of 5m |
||
|
High Q value(NTK made in Japan) Vibrators |
||
|
Stainless steel Drain valve assembled under the bottom |
||
|
Automatic frequency tracking Generator |
||
|
Over-current protection |
||
|
Soft-start function |
||
|
Material |
||
|
Inner cleaning tank |
SUS304L,2.0mm |
|
|
Vibrating side |
SUS 304L,2.5mm |
|
|
Surrounded outside |
SUS 304L,1.0mm |
|
|
Base support |
Stainless steel Square tube 38mmx38mm,1.5mm |
|
|
DC Connector |
no, low voltage power connection |
|
|
Process standard |
||
|
Vibration side |
Hard chrome plated over 0.05mm |
|
|
Appearance |
No glitches, no corners, smooth, beautiful |
|
|
Inner cleaning tank |
Well welded, upright, water-proof |
|
|
Welding spot |
No burn marks, welding marks after polishing |
|
|
Fixed screw |
Ball head smooth |
|
|
Assembled mode of vibrator |
Glued + Screwed |
|
|
Heating rod |
Well insulated, short-cut protected |
|
|
Free spare parts |
||
|
Separated generator, heating rod, fuse |
||
|
Packing |
||
|
Wooden case with pallet, easy operated by fork Supported under the bottom avoid impacting during delivery Stretch seal around |
||
MFR: KEEPLEADER™ have modified and designed Industrial Cleaning Ultrasonic Agitation Degreasing Machine for our customers’ unique and special requirements, please contact KEEPLEADER™ for updated details
Industrial Cleaning Ultrasonic Agitation Degreasing Machine has CE certification
Industrial Cleaning Ultrasonic Agitation Degreasing Machine has auto frequency sweeping functionality for best consistent cleaning performance
