Mobile crusher stone granite limestone gravel jaw crusher machine stone crushing small rock crushers for sale

Mobile crusher stone granite limestone gravel jaw crusher machine stone crushing small rock crushers for sale

FOB Reference Price: Get Latest Price

≥1 Sets

US $50000

≥10 Sets

US $30000

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Weight:: 2800 KG, 2800 KG

Model:: PE250X400

Feeding Opening size:: 250x400 mm

Max Feeding size:: 250 mm

Discharge size:: 0-20 mm

Capacity:: 5-20 tph

Power:: 15 KW

Dimension:: 1180x1087x1245 mm

Color:: Customer Requirement

Applicaton:: stone

Quick Details

Application:: Mining Quarry Building Construction

Capacity(t/h):: 3-300 tph

Place of Origin:: Henan

Weight:: 2800 KG, 2800 KG

Model:: PE250X400

Feeding Opening size:: 250x400 mm

Max Feeding size:: 250 mm

Discharge size:: 0-20 mm

Capacity:: 5-20 tph

Power:: 15 KW

Dimension:: 1180x1087x1245 mm

Color:: Customer Requirement

Applicaton:: stone

Mobile Crusher

PC Series Mobile Jaw Crusher Plants

Type: Mobile Crusher

Capacity: 16-450TPH

Applications:Primary crusher in mining, quarry, mixing and batching plant, road and building construction, highway, railway and subway, and water conservancy.

Input Size: 340-780mm

Processed Materials:Limestone, Granite, Gabbro, Basalt, River Stone, Coal Gangue, Quartz, Diabase,Iron Ore, Copper Ore, Zinc Ore, Manganese Ore, etc.

Mobile Crusher Introduction

Discharge opening of the pc series mobile jaw crusher is adjustable reliably within a wide range through the stuffing of shim, thus it is capable to meet various requirements of customers,Lubrication system of it is safe and reliable, which boasts an easy and convenient maintenance,simple structure, reliable , low maintenance cost.

Mobile Crusher Features

1.Compact frame classis decreases the length of material conveying.

2.Easily adopted from single crushing application to multi-crushers cooperation.

3.Pre-screening function makes much more capacity ever.for the whole machine.

4.Exchangeable on the main machines satisfy the various needs from clients.

5.The flexiable and motorized parking features ensure its immediate operating mode.

Mobile Crusher Specification

PC Series Jaw Plants
PC JAW PLANTS	PC600	PC750	PC900	PC1060	PC1200
Transport dimensions
Length(mm)	8700	9326	10700	12500	14450
Width(mm)	2360	2490	2780	2900	3000
Height(mm)	3765	4125	3840	4450	4800
Weight(t)	17.4	27	35.4	60	82
Axle weight(t)	8.1	16	25	40.5	52
Traction pin/Loading weight(t)	50/9.3	50/11	50/10.4	90/19.5	90/30
Jaw crusher
Model	PE400X600	PE500X750	PE600X900	PE750X1060	PE900X1200
Feed opening(mm)	400X600	500X750	600X900	750X1060	900X1200
Max Feeding size(mm)	340	425	500	630	780
Setting range(c.s.s)(mm)	40-100	50-100	65-180	80-180	95-225
Capacity(t/h)	16-60	40-110	80-180	110-320	220-450
Feeder
Model	GZT0724	GZT0724	ZSW380X95	ZSW490X110	ZSW600X1300
Hopper volume(m³)	3.2	3.2	7.6	10	10
Hopper width(mm)	2200	2200	3150	3000	3000
Belt conveyor
Model	B600X5.8Y	B650X5.8Y	B1000X7.0Y	B1000X7.2Y	B1200X8.3Y
Side Belt conveyor(optional)
Model	/	B400X2.7Y	B500X2.7Y	B500X2.7Y	B650X3.5Y
Magnetic separator(optional)
Model	RCYD-6.5	RCYD-6.5	RCYD-10	RCYD-10	RCYD-12
Number of axles
Number of axles	1	2	2	3	4

Production capacity
