Quick Details
-
Warranty:
-
1 years
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Target
-
Model Number:
-
Y120 electric winch with steel cable
-
Gear Train:
-
3-stage planetary
-
Gear Reduction Ratio:
-
265:1
-
Rated Line Pull:
-
12000LB(5443kg) single-line
-
Certification:
-
Reach
-
Certifications:
-
CE
Quick Details
-
Power Source:
-
Electric
-
Application:
-
AUTO
-
Capacity:
-
3500lb
-
Warranty:
-
1 years
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Target
-
Model Number:
-
Y120 electric winch with steel cable
-
Gear Train:
-
3-stage planetary
-
Gear Reduction Ratio:
-
265:1
-
Rated Line Pull:
-
12000LB(5443kg) single-line
-
Certification:
-
Reach
-
Certifications:
-
CE
Product Description
specification
Rated Line Pull: 3000LB(1361kg) single-line
Motor: 3.0hp/2.2kw 12V, Permanent Magnet Motor
Gear Train: 1-stage planetary
Gear Reduction Ratio: 153:1
Clutch: pull and push
Cable φ3/16”×42.6” (φ4.8mm×13m)
Drum Size: φ1.5”×2.83”(φ38mm×72mm)
Overall Dimensions: (L×W×H)13.3”×4.8”×4.65”(338×123×118mm)
Gross Weight: 19.4 lbs(8.8kg)
Duty Cycle: Intermittently
Fairlead: 4-way roller fairlead
Package: 1pc/box 415×345×163mm
Mounting Bolt Pattern: 5.1"x3.15”(130×80mm )
Features
1. Powerful motor with good quality and thick copper rotator generates high horse power, supplying sufficient power for heavy duty pulling capacity.
2. High strength tempered steel gears guarantee firm toughness performance in extreme off road circumstances.
3. Automatic braking action, reliable and stable.
4. Aircraft grade hot-galvanized steel cable, tough and anti-rust, or high strength and toughness UHMWPE rope, to fulfill powerful pulling requirement.
5. This winch is also equipped with pure copper battery wires, and a waterproof one piece design solenoid, durable usage for big amp draw.
6. Wired and wireless remote control, fairlead, rugged hook and installation hardware are included.
7. This winch is ensured to be with superb workmanship and stable performance. 100% quality control is applied in production procedures.
material
steel, aluminum, copper, plastic
Remote Control: Included
Specification
|
item
|
value
|
|
Warranty
|
3 years
|
|
Certification
|
CE
|
|
Customized support
|
OEM, ODM
|
|
Place of Origin
|
China
|
|
Brand Name
|
|
|
Model Number
|
Y120 electric winch with steel cable
|
|
Power Source
|
Electric
|
|
Application
|
AUTO
|
|
Capacity
|
8000lbs
|
|
Gear Train
|
3-stage planetary
|
|
Gear Reduction Ratio
|
265:1
|
|
Overall Dimensions
|
(L×W×H)20.7"×6.4"×8.1"(527×163×205mm)
|
