Quick Details
-
Product name:
-
Cold rolling steel bar ribbed construction bar mesh welding machine
-
Max diameter:
-
5.5mm
-
Finished product diameter:
-
2.0mm
-
Voltage:
-
380V 50Hz
-
Function:
-
making ribbed bar
-
Raw material:
-
low carbon steel wire
-
speed:
-
120m/min
-
Motor:
-
55KW
Quick Details
-
Place of Origin:
-
China
-
Weight (KG):
-
3000
-
Power (kW):
-
55
-
Product name:
-
Cold rolling steel bar ribbed construction bar mesh welding machine
-
Max diameter:
-
5.5mm
-
Finished product diameter:
-
2.0mm
-
Voltage:
-
380V 50Hz
-
Function:
-
making ribbed bar
-
Raw material:
-
low carbon steel wire
-
speed:
-
120m/min
-
Motor:
-
55KW
Product Description
Cold rolling steel bar ribbed construction bar mesh welding making machine
The machine is fully enclosed, with little dust, equipped with four driven wheels, the middle wheel can be adjusted up and down, and the lifting mechanism is a worm wheel, a worm, and a worm with a large hand wheel, which facilitates the penetration and adjustment of the base material to the best effect of descaling.
Specification
|
Input wire diameter
|
5.5mm
|
|
Output ribbed diameter
|
2.0mm
|
|
Max speed
|
230m/min
|
|
Capacity
|
750kg/hour
|
|
Main power
|
60kwkw
|
|
Reducer
|
special large medium hard gear surface reducer
|
|
speed adjustment mode
|
digital speed control technology
|
|
Overall dimension
|
7.2m*1.4m*2.2m
|
|
Weight
|
3.5T
|
