Detail of Big Outdoor Marquee Party Tent Wedding Decoration Aluminum Alloy Frame

Frame material	1. High pressed extrued aluminum alloy 6061-T6(13HW) 2. Sizes of cross section of main profile:: 84 x 48 x 3mm, 120 x 48 x 3mm, 120 x 68 x 3mm, 166 x 88 x 3mm, 203 x 112 x 4mm, 255 x 112 x 4.5mm, 300 x 125 x 5mm, 300 x 125 x 8mm 3. Durable, lightweight, easy set up, not easy to rust and distort 4. Eave connection: hot-dip galvanised steel insert.
Steel parts & Connection	Inset joint, hot-dipped galvanized, Passed 144 hour of salt spraying test
Fabric material	roof cover: 850g/sqm blackout Polyester with double side PVC coated, Waterproof, Flame-retardant, Anti-UV aging High quality spread coat PVC roof panels with PVDF lacquer coating for optimum cleanability. • High frequency welded for optimum strength, durability, look and quality. • Walls are a 2-piece design with centre lacing. • Sides slide into keder grooves in each leg. They are suspended on unique new nylon gliders that engage in a keder groove on the underside of each eave purlin. • Walls are secured at the bottom by a base rail for maximum security. • A wide range of sidewall options are available including Plain, Clear, Panorama, Cottage and French Window styles.
Option Accessories	Grass anchors, lining, light, Glass door, glass wall, wood flooring, slide glass door and so on
Loading Specification of Luxury marquee wedding party tent with ceilings curtains and partition
Wind Load	Max. to 100km/h to 120km/h
Snow loading	0.5kn/square meter
Working temp	-35C to +75C

Available Sizes of Big Outdoor Marquee Party Tent Wedding Decoration Aluminum Alloy Frame

Unit combination style structure. The span is from 3meters to 60 meters, such as 6m, 8m,9m 10m,12m, 15m, 18m, and the length is unlimited, 3m/5m bay. Size can be customized.

Wide	Bay Distance	Side Height	Ridge Height	Roof Pitch	Wind Load	Frame Profile Size
6m	3m	2.5m	3.7m	18°	80-100km/h	84 x 48 x 3mm
8m	3m/5m	2.5m	4.1m	18°	80-100km/h	120 x 68 x 3mm
9m	3m/5m	2.5m	4.3m	18°	80-100km/h	120 x 68 x 3mm
10m	3m/5m	2.5m	4.5m	18°	80-100km/h	120 x 68 x 3mm

Wide	Bay Distance	Side Height	Ridge Height	Roof Pitch	Wind Load	Frame Profile Size
12m	3m/5m	4m	6m	18°	80-100km/h	166x88x3mm
15m	3m/5m	4m	6.5m	18°	80-100km/h	166x88x3mm
18m	3m/5m	4m	7m	18°	80-100km/h	166x88x3mm

Wide	Bay Distance	Side Height	Ridge Height	Roof Pitch	Wind Load	Frame Profile Size
20m	5m	4m	7.2m	18°	80-100km/h	200x115x4mm
25m	5m	4m	8.0m	18°	80-100km/h	250x115x4mm
30m	5m	4m	8.8m	18°	80-100km/h	300x125x4mm

Wide	Bay Distance	Side Height	Ridge Height	Roof Pitch	Wind Load	Frame Profile Size
40m	5m	4-5m	9.8m	18°	80-100km/h	300x125x4mm
50m	5m	4-5m	11.4m	18°	80-100km/h	300x125x5mm
70m	5m	4-5m	15.3m	18°	80-100km/h	400x140x6mm

Application situations:

1. Wedding ceremony or banquets

2. Garden party and small gathering

3. Outdoor meeting, advertising, promotion

4. Fetes ( concerts, beer festivals, gourmet food festivals)

5. Entrance canopy or shelter, attached to a big marquee

6. Exhibition and trade fairs ( promotion, market fairs, launching)

7. Arenas, walkways, garaging, storage, stabling, open/ close ceremony, reception.

Our tents have been supplied to 2008 Beijing Olympic Games, 2014 Nanjing YOG, 2010 Shanghai World Expo, Shanghai Fashion Shows, and many other international events.

Optional accessories of Big Outdoor Commercial Trade Show Event Exhibition Tent

1. Roof Covers: Transparent, Translucent, block out PVC covers;

2. Sidewall: Soft PVC,Glass, ABS, Steel sheet, Sandwich panel;

3. Doors: Glass door, Sliding door, Rolling door, Double-wing door, Aluminum;

4. Lining Decoration: Roof lining, Wall Curtain, Lighting;

5. Flooring,Rain gutter,Ventilation system, Extended Ramps;

6. Transport and storage rack for doors

Fixing Methods

Ground anchor(steel peg): For soft ground surface like, earth, sand, lawn, etc.

Inflatable screw: For hard surface like, cement, stone, or prefab concrete cubic, etc.

Weight plate: For protective ground surface like marble, ceramic & tiles, asphalt, brick, etc.

Our Certificates

1. TUV Rheinland certification;

2. ISO9001 quality system certification;

3. the international tent Industry Association;

4. 2008 Beijing Olympic Games official partner of Honor;

5. France M2 class fire certificate, German DIN4102 B1 level fire certificate, California in the United B701-fire certificate;

6. China Exhibition Industry Association;

7. China's top ten best-selling brands tent industry;

8. China Shou contract re-credit enterprise

Suzhou WT Tent Co., Ltd. is a combination of trading agency and manufacturer located in Suzhou,China. We own specialized Aluminum-Alloy Structure tent, workstations, modernized production line and advanced technique. Our main products include  trade show tent, premium marquees, big party tent,large exhibigtion tent,pagoda,summer gazebo,folding tent,instant pop up tent, which are widely exported to American, European ,Middle east and Oceanian markets.

We are reputed for providing high quality products and efficient customer support at a reasonable price since our establishment. The number of our clients doubles continually by the step of our expanding.

Our Markets

√ North America √ South America √ Western Europe √ Eastern Europe

√ Eastern Asia √ Southeast Asia  √ Middle East √ Africa  √ Oceania

The quality and diversification of products has been widely recognized international customers, so the company in Australia, the United States, Japan, New Zealand, France, Norway, has a direct agency, to facilitate foreign customers buy nearby

1. Any interior pole in the Tent? How to hide them?

NO pole inside. 100% use of the space. Satin liner and curtain to hide the frame are available.

2.Tent for 1000 people,what size do I need?

For wedding tent with talbes and chairs,1 people -1.5sqm.

For seater tent,1 pepople -1.2sqm.

So 1000 people with tables need 1500sqm,you can use our big tent BTA25*60.

3.Any LOGO?

Yes, any logo is available for you.

4.Hot or Cold in our country, any Air Conditioner?

Yes, we have integral air conditioner espacially for tent event-5HP(50sqm),10HP(100sqm) and 30HP(sqm).

5.How can I get the price?

To make a proper quotation, could you tell me what is the usage of the tent,wedding party tent or warehouse tent?What's the capacity do you need,like for how many people?

6 .What is the leading time? Payment term?

Leading time is 10-20 working days, 30% as deposit paid before production, the rest 70% should be paid before loading.

7. Is your tent able to install repeatedly?

Yes. Our tents can be assembled and dismantled and repeatedly with small transportation size. The lifespan of aluminum framework is more than 30 years, and 10 years for PVC fabrics depending on different

conditions of usage.

8. What documents are available?

A full range documents including design drawings, packing list, installation manual and relative certificates can be provided. Moreover, we can help you arrange the shipment and customs clearance.

9. How can I install the tent?

We will send you installation manual, and you can send your people to our factory to learn how to install tent. Meanwhile, if you need, we can arrange our technician to your site place to guide the installation.

Payment and shipping time

(1) At present we accept payment made by cash, bank transfer, Western Union and L/C.

(2) At least 30% of the invoice value as deposit, the balance shall be cleared before delivery .
(3) The delivery time shall be 25 working days after receipt of the deposit .

Warranty

(1) We 100% Guarantee your Satisfaction.

(2) Discount can be offered for repurchase of fabric.
(3) Under normal circumstance, the tent could be well working more than 10 years.
