Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
NEWMAX
-
Model Number:
-
TG-1140E
-
Operation System:
-
UCOS
-
Features:
-
OTHER
-
Keyboard:
-
button
-
Product name:
-
DVB-S2 T2 Cdecoder
-
main country:
-
Africa/other
-
Wifi:
-
USB WiFi Dongle
-
Support:
-
Protocol Supported
-
Function:
-
Youtube
-
type:
-
dvb t2+dvb s2 receiver
-
Material:
-
Steel
-
Language:
-
Support Multi Languages
-
Certification:
-
ce
Quick Details
-
Processor Core:
-
8001
-
Support Resolution:
-
1920 x 1080
-
WiFi:
-
802.11n 2.4GHz
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
NEWMAX
-
Model Number:
-
TG-1140E
-
Operation System:
-
UCOS
-
Features:
-
OTHER
-
Keyboard:
-
button
-
Product name:
-
DVB-S2 T2 Cdecoder
-
main country:
-
Africa/other
-
Wifi:
-
USB WiFi Dongle
-
Support:
-
Protocol Supported
-
Function:
-
Youtube
-
type:
-
dvb t2+dvb s2 receiver
-
Material:
-
Steel
-
Language:
-
Support Multi Languages
-
Certification:
-
ce
Products Description
|
SPECIFICATIONS
|
|
|
||
|
SECTION
|
ITEM
|
DESCRIPTION
|
||
|
PROCESSOR
|
CPU
|
Montage CS8001-S030
|
||
|
|
Flash Memory
|
4MB
|
||
|
|
DDR2
|
64MB
|
||
|
DVB-S/S2 TUNER
|
Input Frequency:
|
950 ~2150MHz
|
||
|
|
Inpul level:
|
-80~-20dBm
|
||
|
|
Input impedance
|
75Ω
|
||
|
DVB-T/T2 Tuner Compllan with 36275 VB-T. N 30 744 DvB-i2 Standarts
|
Input Frequengy Range
|
VIF 170~ 20MHZUHF 47~ 862MHz
|
||
|
|
IF Bandwidth
|
6MHz/ 7MHz/ 8MHz
|
||
|
|
Input Signal Level
|
-85dBm ~- 20dBm
|
||
|
|
Input impedance
|
75Ω
|
||
|
|
RF Input Connector
|
IEC 61169-2 antenna female connector
|
||
|
DVB-C Tuner, Complian with. EN 300 429 DVB-C Standart
|
Input frequency Range
|
48MHz ~ 1GHz
|
||
|
|
Guard interval
|
1419128,18/19/256,16132./128
|
||
|
|
FEC Code rates
|
1/2,2/3,3/4,3/5,4/5,5/6
|
||
|
DEMODULATOR
|
OFDM
|
16QAM,32QAM, 64QAM, 128QAM, 256QAM
|
||
|
DECODING
|
Demodulation
|
QPSK, 8PSK, 16PSK
|
||
|
|
FEC mode
|
DVB-S:1/2,2/3, 3/4, 5/6.7/8
|
||
|
|
|
DVB-S2: 12. 315. 23. 314. 45, 516, 89. 910 (QPSK) 3/5, 2/3, 3/4, 5/6, 8/9, 9/10 (8PSK)
|
||
|
|
Symbol Rate
|
DVB-S: 2.0~45 MS/s
|
||
|
|
Demodulation
|
QPSK, 8PSK, DVB-S2: 10-30 Mb/s (QPSK), 10-31Mb/s (8PSK)
|
||
|
|
|
|
||
|
DEMULTIPLEXER
|
Standard
|
ISO/IEC 13818-1
|
||
|
|
Input Max. Bit Stream Rate
|
100Mbps(Serial)/12.5MBp(Pralle)
|
||
|
VIDEO DECODING
|
Standard
|
ISOIEC 13818-2, MPEG-2 MP@ML, MPEG4 AVC (MP L4.1)
|
||
|
|
Aspect Ratio
|
4:3, 16:9
|
||
|
|
Video Format
|
PAL -B/NTSC-M/PAL-N/PAL-M
|
||
|
|
Video Resolution
|
1080P, 10801,720P ,480P/576P ,480v576iSD compatible
|
||
|
AUDIO DECODING
|
Standard
|
ISO/IEC 13818-3
|
||
|
|
Decoding
|
MPEG-1 Layer i and m MPEG-2, MPEG4 AAC
|
||
|
|
Output Mode
|
LPCM, RAW
|
||
|
|
Sampling Frequency
|
32,44.1.48KHz
|
||
|
|
Volume Level
|
24 Levels
|
||
|
AV OUTPUT
|
Video de emphasis
|
CCIR REC.405-1.625LINES
|
||
|
|
Video bandwidth
|
5.5MHz
|
||
|
|
Video output impedance
|
75Ω
|
||
|
|
Video output level
|
1.0Vp-p
|
||
|
|
Audio output
|
Stereo
|
||
|
|
Audio output frequency
|
20Hz~ 20KHz
|
||
|
|
Audio output impedance
|
Low
|
||
|
|
Audio output level
|
A1.0Vms±2dB into 10K.
|
||
|
AV OUTRUT
|
Panel Intertace
|
●1×AV(CVBS+R/L AUDIO) ●1×HDTV ●1×LNB IN ●2×USB 2.0 port
|
||
|
OTHERS
|
Power input Spec.
|
12v/1A DC IN Max.12v
|
||
