Quick Details
-
Model Number:
-
W-110B/W-215
-
Dimension:
-
280*440*455mm
-
Storage:
-
Other
-
SNR:
-
Other
-
Output Power:
-
350W RMS
-
Format:
-
two-way line array system
-
Type:
-
line array system
-
Frequency Response:
-
65Hz-18KHz±3dB
-
Color:
-
Black
-
Nominal impedance:
-
16 ohm
-
Coverage:
-
110°H*10°V
-
Finsh:
-
Textured high-density polyurethane coating
-
Sensitivity:
-
LF 101dB(1W@1M) HF 103dB(1W@1M)
-
Max SPL:
-
LF 128dB(PEAK/1M) HF 131dB(PEAK/1M)
-
Connectors:
-
2*NL4MP speakon
-
Enclosure Material:
-
Birch Plywood
Quick Details
-
Warranty:
-
1year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CVR
-
Model Number:
-
W-110B/W-215
-
Dimension:
-
280*440*455mm
-
Storage:
-
Other
-
SNR:
-
Other
-
Output Power:
-
350W RMS
-
Format:
-
two-way line array system
-
Type:
-
line array system
-
Frequency Response:
-
65Hz-18KHz±3dB
-
Color:
-
Black
-
Nominal impedance:
-
16 ohm
-
Coverage:
-
110°H*10°V
-
Finsh:
-
Textured high-density polyurethane coating
-
Sensitivity:
-
LF 101dB(1W@1M) HF 103dB(1W@1M)
-
Max SPL:
-
LF 128dB(PEAK/1M) HF 131dB(PEAK/1M)
-
Connectors:
-
2*NL4MP speakon
-
Enclosure Material:
-
Birch Plywood
Product Description
|
Model
|
W-110B&W-110BP
|
|
Type
|
Two-way line array system
|
|
Frequency Response
|
65Hz-18KHz±3dB
|
|
Power handling
|
LF 350W(RMS)1400W(PEAK)
|
|
|
HF 110W(RMS)440W(PEAK)
|
|
Sensitivity
|
LF 101dB(1W@1M)
|
|
|
HF 103dB(1W@1M)
|
|
Max SPL
|
LF 128dB(PEAK/1M)
|
|
|
HF 131dB(PEAK/1M)
|
|
Drivers
|
LF 1×10"(260mm)neodymium woofer 75mm(3in)coil
|
|
|
HF 1×3" neodymium compression driver with75mm titanium diaphragm
|
|
Nominal impedance
|
LF 16 ohm
|
|
|
HF 16 ohm
|
|
Coverage
|
110º H×10º V
|
|
Connectors
|
2×NL4MP speakon
|
|
Connections
|
LF 1(+)1(-) HF 2(+)2(-)
|
|
Finish
|
Textured high-density polyurethane coating
|
|
Enclosure Material
|
Birch Plywood
|
|
Dimensions
|
280×440×455mm(W×H×D)
|
|
Packing Dimensions
|
350×520×525mm(W×H×D)/0.1cbm
|
|
Net weight
|
18kg(W-110B)/20kg(W-110BP)
|
|
Gross weight
|
21.5kg(W-110B)/23.5kg(W-110BP)
|
