Quick Details
-
Model Number:
-
NBB3-V3-Z4
-
Type:
-
Double wire type
-
Power:
-
36W
-
Sensing Range:
-
3 mm
-
Product name:
-
Touch Switch Capacitive Sensor
-
Certification:
-
CE
Quick Details
-
Voltage:
-
5 ... 60 V DC
-
Place of Origin:
-
GUA
-
Brand Name:
-
P+F
-
Model Number:
-
NBB3-V3-Z4
-
Type:
-
Double wire type
-
Power:
-
36W
-
Sensing Range:
-
3 mm
-
Product name:
-
Touch Switch Capacitive Sensor
-
Certification:
-
CE
Product Description
Specification
|
item
|
value
|
|
Place of Origin
|
GUA
|
|
Brand Name
|
P+F
|
|
Model Number
|
NBB3-V3-Z4
|
|
Warranty
|
Other
|
|
Type
|
Double wire type
|
|
Certification
|
CE
|
|
Power
|
36W
|
|
Voltage
|
5 ... 60 V DC
|
|
Customized
|
NO
|
|
Sensing Range
|
3 mm
|
|
Whether the smart
|
NO
|
|
Product name
|
Touch Switch Capacitive Sensor
|
The technical parameters are excerpted from NBB3-V3-Z4
General specification
Switch function normally on (NO)
Output type double-wire
Rated working distance 3 mm
Flush mounting
Output polarity DC
Make sure the operating distance is 0... 2, 4mm
Actual working distance 2,7... 3,3 mm
Attenuation coefficient rAl 0,45
Attenuation coefficient rCu 0,35
Attenuation coefficient r304, 0,8
Attenuation coefficient rBrass 0,5
Output type 2 lines
rating
Operating voltage 5... 60 V DC
Switching frequency 0... 2000 Hz
Hysteresis type 0,2 mm
Reverse polarity protection Reverse polarity protection
Short circuit protection none
Inductive overvoltage protection is
Voltage drop ≤ 4 V
Pressure drop at IL
Voltage drop IL = 10 mA, switch element on 3,4... 3,9 V Type 3,6 V
Operating current 4... 100 mA
Minimum working current 4 mA
Off-state current 0,4... 0,55 mA Type 0,46 mA
Time delay before availability ≤ 1 ms
Switch status indicator yellow LED
Limit data
The tightening torque of the fastening screws is 0, 4nm
Functional safety-related parameters
MTTFd 1552 a
Task time (TM) 20 a
Diagnostic coverage (DC) 0 %
Comply with standards and instructions
Meet the standard
Standard EN 60947-5-2:2007
EN 60947-5-2/A1:2012
IEC 60947-5-2:2007
IEC 60947-5-2 AMD 1:2012
Certification and certificate
UL Certification cULus Certification, general purpose
CSA Certified by cCSAus Certified, general purpose
CCC certification passed China Compulsory Product Certification (CCC)
Environmental conditions
Ambient temperature -25... 85 °C (-13... 185 °F)
Mechanical specification
Connection type Cable PVC, 130 mm
The cross-sectional area of the core is 0,14 mm2
Shell material PBT
Induction surface PBT
Protection level IP67
cable
Cable diameter 3 mm ± 0 mm 2 mm
Bend radius > 10 x cable diameter
Mass 7,5 grams
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
