Quick Details
-
Model Number:
-
125CLHG-12
-
Color:
-
Silver
-
FACE:
-
graphite/silicon carbide/tungsten carbide
-
Keyword:
-
cartridge mechanical seal
-
Name:
-
125CLHG-12
-
Temperature:
-
-40°C~220°C
-
speed:
-
25m/s
-
pressure:
-
up to4.0Mpa
-
Axial movement:
-
±0.5mm
-
cecondary saaling:
-
NBR/FKM/EPDM/SILICON RUBBER/PTFE
Quick Details
-
Size:
-
32mm, 32mm
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
xdseal
-
Model Number:
-
125CLHG-12
-
Color:
-
Silver
-
FACE:
-
graphite/silicon carbide/tungsten carbide
-
Keyword:
-
cartridge mechanical seal
-
Name:
-
125CLHG-12
-
Temperature:
-
-40°C~220°C
-
speed:
-
25m/s
-
pressure:
-
up to4.0Mpa
-
Axial movement:
-
±0.5mm
-
cecondary saaling:
-
NBR/FKM/EPDM/SILICON RUBBER/PTFE
|
Performance Capabilities
|
Materials combination
|
|
Temperature: -40°C to 220°C, dependent on the o ring
|
Sealing Face:Graphite, Silicon carbide, Tungsten carbide
|
|
Pressure: Up to 4.0Mpa
|
Secondary sealing: Acrylonitrile rubber, Fluorine rubber
Ethylene propylene rubber, Silicon rubber, PTFE
|
|
Speed: Up to 25 m/s
|
Metal component: 304 or 316L stainless steel
|
|
axial float allowance: ±1.0mm
|
Spring: SS316, hastelloy C
|
|
Sizes: 45mm
|
|
.
Q:Are you trading company or factory ?
A:We are a factory .
Q:Where is your factory located ?
A:our factorty is located in Jiande, jiaxing .
Q:How long is your delivery?
A:For stock items ,we can ship them immediately after receive payment .
For other items,we will need 20 days for mass production.
Q:Do you provide free samples ?
A:Usually we do not provide free samples .There is a sample cost which can be refund after you place order .
Q:What do you usually shipped through?
A:Air freight, Sea freight,express are the most way of shipment due to small weight and size for precise products.
Q:What's your payment terms ?
A:We accept T/T, Paypal, Western Unionwhen qualified goods are ready for ship.
Also pay to Alibaba is welcome.
Q:I can not find our products in your catalog ,can you make customized products for us ?
A:Yes ,Customized products is available .
Q:I don't have drawing or picture available for custom products, could you design it?
A: Yes,we can make the best suitable design in accordance with your application.
