Quick Details
-
Voltage:
-
380V/50HZ(Price vary if power different)
-
Dimension(L*W*H):
-
1080*550*1050mm
-
Weight:
-
130 KG
-
Power:
-
5HP
-
Working Temperature Range:
-
5℃ to 35℃
-
Product name:
-
Chiller
-
Cooling type:
-
Water cooled
-
Model:
-
YMWC-5HP
-
Cooling capacity:
-
10662Kcal/h
-
Compressor power:
-
3.15KW
-
Condenser type:
-
Sleeve type(Hub pipe type optional)
-
Condenser water flow:
-
2.6m3/h
-
Refrigerant:
-
R22(Can be customized)
-
Payment terms:
-
T/T, Western Union,L/C
-
Business type:
-
Manufacture(OEM and ODM)
Quick Details
-
Condition:
-
New
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Binyi Plastics Machinery
-
Voltage:
-
380V/50HZ(Price vary if power different)
-
Dimension(L*W*H):
-
1080*550*1050mm
-
Weight:
-
130 KG
-
Power:
-
5HP
-
Working Temperature Range:
-
5℃ to 35℃
-
Product name:
-
Chiller
-
Cooling type:
-
Water cooled
-
Model:
-
YMWC-5HP
-
Cooling capacity:
-
10662Kcal/h
-
Compressor power:
-
3.15KW
-
Condenser type:
-
Sleeve type(Hub pipe type optional)
-
Condenser water flow:
-
2.6m3/h
-
Refrigerant:
-
R22(Can be customized)
-
Payment terms:
-
T/T, Western Union,L/C
-
Business type:
-
Manufacture(OEM and ODM)
|
Model
|
YMWC-5HP
|
|
Voltage
|
380V/50HZ(Price vary if power different)
|
|
Nominal output
|
50HZ 42334Btu/h 12.4KW 10662Kcal/h 3.5USRT
|
|
New
Panasonic
compressor power
|
3.15KW
|
|
Condenser water flow
|
2.6 m³/h
|
|
Condenser diameter of nipple
|
32DN
|
|
Condenser style
|
Sleeve type
|
|
Evaporator Water tank capacity
|
55L
|
|
Standard freezing water flow
|
2.2 m³/h
|
|
Diameter of standard nipple
|
32DN
|
|
Built-in pump horsepower
|
0.5HP
|
|
Refrigerant
|
R22
|
|
Electrical
|
TECO
brand
|
|
Computer control
|
Punp
brand
|
|
Machine dimension
|
1080*550*1050mm
|
|
Weight
|
130KG
|
