Qipang TC1200mm spool winding machine large wire cable drum rewinding spool rewinding machine automatic take up machine
A, coiling winder
B, spool winder
Shanghai Qipang TC800 spool winder machine manufacturer large wire electric cable rewinding machine equipment
1. For example, if you want to realize: release from the large roll and then need 30 meters or 50 meters and then automatically stop, use the pivot to rewind the small axis.I need to know the specific size of your big axis and small axis.This one needs a meter in the middle.
2, you are from the winding shaft to the hollow coil, and then a roll to sell customers, this is the need for the winding machine.
3. After the wire comes out of the assembly line, it needs to be rewound to check whether the diameter of the wire is qualified.It needs to be rewound, and a caliper and spark machine should be added in the middle.
4. When the wire comes out of the assembly line, it needs to print its own LOGO, and in the middle, it needs a printer.
PN1000MM SPOOL PAY OFF MACHINE
Active disconnecting with motor +
Dance round (φ250,5+6）+ meter + PN1250 winding machine .
Slow stop, automatic stop, buffer speed, flexible brake.
Product Description
|
bobbin size PAY OFF
|
630mm/800mm
|
Power
|
2.2/4KW
|
1000MM
|
|
meter counter
|
yes
|
max load
|
3000kg
|
yes
|
|
speed
|
300r/min
|
up and down
|
motor
|
|
|
winding device
|
rolling ring drive
|
take up machine
|
400mm/500mm/630mm
|
|
Title goes here.
The difference between active payoff and passive payoff: active take-up has motor, passive pay-off is no motor pull by pull-up
machine, speed is uncontrollable.
machine, speed is uncontrollable.
1. Applicable wire reel PND400- 600mm-800MM-1000MM-1250MM-1500MM
2. Discharge method: active release
3. Chuck mode: no
shaft thimble clamping
shaft thimble clamping
4. Lifting method: oil pressure lifting
5. Take-up motor: 4KW
6. Inverter power, 4KW
7. Line speed: 0-300 m
/ min
/ min
8. Storage line guide wheel outer diameter: 250mn (aluminum alloy made up to five down four)
9. Line type: vertical type
10.Braking method: pneumatic brake
11. Linkage with the customer's previous equipment 12. Machine color: sea blue + beige orange
Φ630-Φ1000mm active pay-off machine
1. Adapt to bobbin flange OD diameter: Φ630-Φ1000mm, Φ1000mm, overall
2. width 475-750mm, inner hole 56/80
3. Top shaft mode: no shaft top cone pneumatic top tight
4. Pay-off speed: MAX200 m / min
5. Clamp the bobbin: 0.75KW electric screw lift
6. Power: 4KW motor drive spool release line
7. Brake: 10KG electromagnetic brake
8. Maximum load capacity: 3000 kg
Vertical tension storage Accumulator/Dancer
1. Total height of 2 meters;
2. The storage line volume is 0-15 meters, and the storage line wheel is Φ400mm(4 groups + 3 groups);
3. Adapt to the wire diameter: 0.5-10mm2 hard wire, Ф15mm soft wire;
4. Guide wheel material: aluminum alloy material, surface hardening treatment;
5. Control mode: The sensor gives a 0-10V voltage signal to control the speed of the line.
Meter counter
1. Form: one-way stop;
2. The surface of the meter wheel and the pressure roller adopts a rubber wheel to ensure that the wire is not damaged.
400-1250 shaftless winding machine
1. Adapted to bobbin flange OD diameter: PN400-PN1250, coil width 280-800mm,
2. inner hole diameter Φ56mm
3. Applicable line speed: 200m/min
4. Top shaft mode: no shaft top cone
5. Clamp the bobbin: electric screw lifts, the upper and lower limits are safe and reliable
6. Cable: GP30 rolling ring drives, adjustable pitch. Wire winding : 10N.M torque motor winding wire
Related Products
Packing & Delivery
Custom packaging
Package
Loading and delivery
FAQ
Q: Are you a factory or a trading company?
A:We are a factory.If you buy our machines, we can guarantee the most Short delivery time and best price.We also have our own trading department.
Q: How does the factory ensure product quality?
A: With nearly 16 years of production experience in winding machine, it has its own technical development department and testing department.We have a strict procurement system to ensure the quality of parts. We have experienced workers to assemble and test machines.
Q: What are your terms of delivery?
A: 1. Full payment if have stock.
2. For customized products, 50% will be paid in advance and 50% will be paid before delivery.
Q: Can you provide us with operating instructions?
A: We will send you the manual together with the machine and video to operate the machine.
Q: How long is the warranty?
A: 12 months warranty, if there is any quality problem, we will give you free spare parts within a week.
Q: Is it possible to visit your factory?
A: Welcome to our factory.We would like to make an invitation for you.I hope we can cooperate for a long time.
