Quick Details
-
Color:
-
full color
-
Panel Size:
-
500x500mm, 500x500mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P4.81
-
Brightness:
-
800-1000nits, 800-1000nits
-
pixel density:
-
43264, 43264
-
Contrast Ratio:
-
5000:1, 5000:1
-
Lifespan (hours):
-
100000, 100000
-
IP Rating:
-
ip43, ip43
-
HS Code:
-
8528591090
-
View Angle（H/V）:
-
140/140, 140/140
-
Display Function:
-
Video
-
LED chip:
-
kinglight
-
controller:
-
Linsn/Nova
-
power supply:
-
meanwell
-
cabinet size:
-
500x500mm
-
control mode:
-
Synchronous or Asynchronous /RJ45/USB/wifi
-
Display fuction:
-
live show ,video, picture
-
cabinet material:
-
die casting aluminum
-
warranty:
-
5years
-
Tube Chip Color:
-
RGB
Quick Details
-
Application:
-
Indoor, indoor
-
Type:
-
LED
-
Brand Name:
-
coreman
-
Color:
-
full color
-
Panel Size:
-
500x500mm, 500x500mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P4.81
-
Brightness:
-
800-1000nits, 800-1000nits
-
pixel density:
-
43264, 43264
-
Contrast Ratio:
-
5000:1, 5000:1
-
Lifespan (hours):
-
100000, 100000
-
IP Rating:
-
ip43, ip43
-
HS Code:
-
8528591090
-
View Angle（H/V）:
-
140/140, 140/140
-
Display Function:
-
Video
-
LED chip:
-
kinglight
-
controller:
-
Linsn/Nova
-
power supply:
-
meanwell
-
cabinet size:
-
500x500mm
-
control mode:
-
Synchronous or Asynchronous /RJ45/USB/wifi
-
Display fuction:
-
live show ,video, picture
-
cabinet material:
-
die casting aluminum
-
warranty:
-
5years
-
Tube Chip Color:
-
RGB
P4.81 indoor full color led screen
| 500x500mm Indoor Led Cabinet | ||||
| Type | P2 . 604 | P2.976 | P3.91 | P4.81 |
| Pixel pitch | 2.604mm | 2.976mm | 3.91mm | 4.81mm |
| Module size | 250x250 | 250x250 | 250x250 | 250x250 |
| Module resolution (pixel) | 96x96 | 84x84 | 64x64 | 52x52 |
| Pixel density | 147492dots/m 2 | 112918dots/ m 2 | 65536dots/ m 2 | 43264dots/ m 2 |
| Pixel Configuration | SMD1515 | SMD2121 | SMD2121 | SMD2121 |
| Cabinet size (mm) | 500x500 | 500x500 | 500x500 | 500x500 |
| Cabinet resolution (pixel) | 192x192 | 168x168 | 128x128 | 104x104 |
| Scan mode | 32s | 28s | 16s | 13s |
| Cabinet Weight | 7kg | |||
| Average consumption | 180-250w/ m 2 | |||
| Max power consumption | 300-430w/ m 2 | |||
| Brightness | ≥1200-1500cd | |||
| Best View distance | ≥2m | |||
| Viewing angle V/H degree | 140º / 140 º | |||
| Contrast rate | 5000 : 1 | |||
| Refresh rate | ≥1920-3840hz | |||
| Waterproof grade | IP31 | |||
| Grey Scale | 16bits | |||
| Working voltage | 110-220VAC/50Hz | |||
| MTBF | ≥5000hrs | |||
| Life span | 100000hrs | |||
| Certification | CCC/CE/RoHS/FCC/ISO | |||
500x1000mm
Our factory
1)Training after order
After the order is placed, a processional training will be offered, including software use, operate safety, maintain equipment
2) Installation and debugging
Wecould send professionals to conduct on site installation and debugging in strict accordance with the requirements of the schemes and original manual.
3) Warranty
Warranty: 3 years warranty, lifetime maintenance
Equip with free spare parts. The first 2 years after shipment, we will be responsible for free maintenance if any problem caused by quality itself. While you should take the cost of the freight to us. After 2 years, service is still available, but would charge for labor, material and freight cost that generates.
4) Maintenance
Maintenance principles: response in time, solve problems asap and ensure the use.
Maintenance period: In the maintenance period of the led display body, free of all maintenance charges
After maintenance period, only charge the material cost and labor cost.
