Quick Details
-
Model Number:
-
CID2/800-0405
-
Dimension:
-
480*445*88
-
Storage:
-
NONE
-
SNR:
-
>80dB
-
Output Power:
-
800W x 2 channels@8ohm
-
Format:
-
none
-
Class:
-
Class H
-
Height:
-
2U
-
G weight:
-
23.12 kg
-
stereo power 4 ohm:
-
1200watts x 2
-
Material:
-
aluminum/Iron
-
BTL 4ohm:
-
3200watts
-
input sensitiviy:
-
0.775v/1.0v/1.4v
-
damping factor:
-
>200
-
Certification:
-
CE/ROHS
Quick Details
-
Warranty:
-
3months-1year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
WYW
-
Model Number:
-
CID2/800-0405
-
Dimension:
-
480*445*88
-
Storage:
-
NONE
-
SNR:
-
>80dB
-
Output Power:
-
800W x 2 channels@8ohm
-
Format:
-
none
-
Class:
-
Class H
-
Height:
-
2U
-
G weight:
-
23.12 kg
-
stereo power 4 ohm:
-
1200watts x 2
-
Material:
-
aluminum/Iron
-
BTL 4ohm:
-
3200watts
-
input sensitiviy:
-
0.775v/1.0v/1.4v
-
damping factor:
-
>200
-
Certification:
-
CE/ROHS
- CID2 series four channels appearance design patent product. lntegrated with new-launched high performance calss H amplifier and analog transformer power supply.
- It is designed for Karaoke room. It adopts high sound quality TOSHIBA power transistors, with the characteristic of high power efficiency and good sound.
- The main power amplifier is adopted newly self-launched high performance Class H techmology. It has more perfect in terms of recovering waveform and dynamic thermal consumption.
- In such situation, the amplifier is able to make long term and stable operation in the higher temperature environment.
- Professional audio processing technology: linear opto-couple VCA volume control circuit, qutomatic overheat power linear gain control circuit, continuous output short circuit protection.
- Professional color LED display,will show many working information,including the temperature,volume,the model of the signal output ,power supply voltage etc.
|
Model |
CID2/800 |
|
Stereo power 8Ω |
800W*2 |
|
Stereo power 4Ω |
1200W*2 |
|
Stereo power 2Ω |
1600W*2 |
|
BTL 8Ω |
2400W |
|
BTL 4Ω |
3200W |
|
Frequency Response |
20Hz-20KHz±0.3dB |
|
THD+N |
<0.05%@8Ω 1KHz |
|
S/N Ratio |
>80dB |
|
Slew Ratio |
13V/µS |
|
Damping Factor |
>200 |
|
Crosstalk |
>70dB@8Ω 1KHz |
|
Input Impedance |
20K Ω(Balance)/10K Ω(Unbalance) |
|
Input Sensitivity |
0.775V/1.0V/1.4V |
|
Protect |
Overheat short circuits, DC, limit and-softstart,Output relay-Zero Current Switch, Intellctual Clip limiter. |
|
G weight |
23KG |
|
Dimensions (W*H*D) mm |
559*568*155(2U) |
|
Output Circuitry |
Class H |
