Quick Details
-
Application:
-
Building
-
Design Style:
-
Industrial
-
Place of Origin:
-
Istanbul, Turkey
-
Brand Name:
-
BAUMERK
-
Model Number:
-
SBS MEMBRANE
-
Type:
-
ROLL, Waterproof Membrane
-
Product Name:
-
SBS Modified Bitumen Membrane
-
Material:
-
Butyl Rubber+aluminum Foil
-
Color:
-
Black
-
Usage:
-
Roof Waterproof Projects
-
Keyword:
-
Self-adhesive Butyl Rubber Tape
Quick Details
-
Warranty:
-
More than 5 years
-
After-sale Service:
-
Online technical support
-
Project Solution Capability:
-
NONE
-
Application:
-
Building
-
Design Style:
-
Industrial
-
Place of Origin:
-
Istanbul, Turkey
-
Brand Name:
-
BAUMERK
-
Model Number:
-
SBS MEMBRANE
-
Type:
-
ROLL, Waterproof Membrane
-
Product Name:
-
SBS Modified Bitumen Membrane
-
Material:
-
Butyl Rubber+aluminum Foil
-
Color:
-
Black
-
Usage:
-
Roof Waterproof Projects
-
Keyword:
-
Self-adhesive Butyl Rubber Tape
BAUMERK SBS BASED BITUMINOUS WATERPROOFING MEMBRANE ( - 20°C )
Product Description
It is the SBS doped elastomeric water isolation membrane with polyester felt; both sides are coated on with polyethylene film.
Usage Areas
It is used in groundwwork bundling, parking, terrace and sloping roofs, balconies, plant stands, garden terrace, concreteflumes, rain gutters and water tanks, ponds, swimming pools and ornamentals against underground waters and used under the coating in wet areas such as kitchne, bathroom etc.
|
TECHNICAL FEATURES |
METRIC UNIT |
STANDARD |
C 2000 |
C 3000 |
C3000 AL |
PP 3000 |
PP 40 K |
PP 40 Y |
PP 3000 AL |
PP 4000 |
PP 50 K |
PP 50 Y |
PP 4000 AL |
|
Bearing (Fiberglass and polyester felt) |
gr/m2 |
TS 11758-1 |
Fiberglass |
Fiberglass |
Fiberglass |
Polyester |
Polyester |
Polyester |
Polyester |
Polyester |
Polyester |
Polyester |
Polyester |
|
Thickness ± 0.2 |
mm |
TS EN 1849-1 |
2.0 |
3.0 |
3.0 |
3.0 |
3.5 |
3.5 |
3.0 |
4.0 |
4.5 |
4.5 |
4.0 |
|
Temperature Resistance |
C |
TS 11758-1 |
>100 |
>100 |
>100 |
>100 |
>100 |
>100 |
>100 |
>100 |
>100 |
>100 |
>100 |
|
Cold Bending (Maximum) |
C |
TS EN 1109 |
-20 |
-20 |
-20 |
-20 |
-20 |
-20 |
-20 |
-20 |
-20 |
-20 |
-20 |
|
Tensile Strength (Height/ Width) |
N/5 cm |
TS 1908 |
400/300 |
400/300 |
400/300 |
1000/800 |
1000/800 |
1000/800 |
1000/800 |
1000/800 |
1000/800 |
1000/800 |
1000/800 |
|
Elongation at Break (Height/ Width) |
% |
TS 1908 |
2/2 |
2/2 |
2/2 |
40/40 |
40/40 |
40/40 |
40/40 |
40/40 |
40/40 |
40/40 |
40/40 |
|
Top Surface Coating - PE Foil |
- |
TS 11758-1 |
Pe |
Pe |
Al |
Pe |
Min |
Min |
Al |
Pe |
Min |
Min |
Al |
|
Sub-Surface Coating - PE Foil |
- |
TS 11758-1 |
Pe |
Pe |
Pe |
Pe |
Pe |
Pe |
Pe |
Pe |
Pe |
Pe |
Pe |
|
Roll Sizes |
m x m |
TS 11758-1 |
1 X 15 |
1 X 10 |
1 X 10 |
1 X 10 |
1 X 10 |
1 X 10 |
1 X 10 |
1 X 10 |
1 X 10 |
1 X 10 |
1 X 10 |
Advantages of the Product
It is flexible, long-lasting, resistant to the aggressive effects that may occur in the soil, can easily be applied to different types of surfaces and can easily be applied to the details such as dilation, edges of chimney and parapet returns, it has high tensile and breakage stability
Surface Preparation
Application ground should be purified from loose pieces, oil and other chemicals and surface defects are repaired with the BAUMERK REPAMERK 1 or BAUMERK PH 55 is used for corners. It is recommended to use the BAUMERK B PR 101 as a liner on the application surface for a healthfully application.
Application
It is fully adhered to the surfaces with blowpipe flame leaving 10 cm of margin at jointing parts and 15 cm of margin at roll finishing parts.
Storage and Considerations
Rolls must absolutely be stored perpendicularly; rolls should be protected from direct UV and sudden temperature changes, the piercing and cutting operations should not be done after application, used terraces should be protect with floor covering.
