Quick Details
-
Brand Name:
-
/
-
Model Number:
-
S12516G-AF
-
Place of Origin:
-
Beijing, China
-
Model:
-
S12516G-AF
-
Keywords:
-
S12516G-AF core switch +price industrial solution network switch
-
Warranty:
-
12 Months
-
Condition:
-
100% Original Brand
-
MPU slots:
-
2
-
LPU slots:
-
16
-
Maximum power consumption:
-
22400W
-
MPU processor:
-
Quad Core 2.2GHz
-
MPU SDRAM:
-
16 GB
-
MPU Flash:
-
4 GB
Quick Details
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
230.4T/1032Tbps
-
Brand Name:
-
/
-
Model Number:
-
S12516G-AF
-
Place of Origin:
-
Beijing, China
-
Model:
-
S12516G-AF
-
Keywords:
-
S12516G-AF core switch +price industrial solution network switch
-
Warranty:
-
12 Months
-
Condition:
-
100% Original Brand
-
MPU slots:
-
2
-
LPU slots:
-
16
-
Maximum power consumption:
-
22400W
-
MPU processor:
-
Quad Core 2.2GHz
-
MPU SDRAM:
-
16 GB
-
MPU Flash:
-
4 GB
Details Images
Installation Instructions
We will test all the switches before shipping. All the switches are new and original
If you have Any Questions,
CLICK ME!!!
|
|
h3c switch S12516G-AF core switch +price industrial solution network switch
|
|
MPU slots
|
2
|
|
LPU slots
|
16
|
|
Maximum power consumption
|
22400W
|
|
Dimensions (H
x W x D) |
931 x 440 x 857 mm (21U)
36.7 x 17.3 x 33.7 in |
|
Switching fabric module
slots |
6
|
|
MPU Name
|
LSXM2SUPT2
|
|
MPU processor
|
Quad Core 2.2GHz
|
|
MPU SDRAM
|
16 GB
|
|
MPU Flash
|
4 GB
|
|
IPv4
|
Static routing, RIP, OSPF, IS-IS, and BGP4
ECMP
Policy-based routing Routing policy |
|
IPv6
|
IPv4/IPv6 dual stack
IPv6 static routing, RIPng, OSPFv3, IS-ISv6, and BGP4+ VRRPv3 and VRRPv3 load balancing Pingv6, Telnetv6, FTPv6, TFTPv6, DNSv6, and ICMPv6 IPv4-to-IPv6 transition technologies, such as IPv6 manual tunnel, 6to4 tunnel, ISATAP tunnel, GRE tunnel, and auto IPv4-compatible IPv6 tunnel ECMP Policy-based routing Routing Policy IP message fragmentation and reassembly |
|
MPLS/VPLS
|
Support L3 MPLS VPN
Support L2 VPN: VLL (Martini, Kompella) Support MCE Support MPLS OAM Support VPLS, VLL Support hierarchical VPLS and QinQ+VPLS access Support P/PE function Support LDP protocol |
CLOS+ multi-grade multi-plane architecture
High performance GPU, 100T+ floating-point computing capabilities
Industry's first network-specific AI algorithm
The S12500G-AF series switch includes S12504G-AF, 12508G-AF and S12516G-AF, which can adapt to the port density and performance requirements of different network scales, provide strong equipment guarantee for data center network construction, and support INT and Seer Network.
Product Selling Points
Reliability
Through patented hot backup technology, redundant backup of all information on the control plane and data plane and uninterrupted data forwarding are realized in the entire virtual
architecture, which greatly enhances the reliability and high performance of the virtual architecture, and eliminates A single point of failure is avoided and business interruption is avoided.
architecture, which greatly enhances the reliability and high performance of the virtual architecture, and eliminates A single point of failure is avoided and business interruption is avoided.
Distribution
Through distributed cross-device link aggregation technology, load sharing and mutual backup of multiple uplinks are realized, thereby improving the redundancy of the entire network architecture and the utilization of link resources.
Ease of management
The entire elastic architecture shares one IP management, which simplifies network equipment management, simplifies network topology management, improves operational efficiency, and reduces maintenance costs.
