Quick Details
-
Model Number:
-
Color Acrylic Sheet
-
Thickness:
-
1.8-300mm, 1-50mm
-
Size:
-
1250*1850mm and so on, 1220*2440mm, 1220*1830mm or customized
-
Product name:
-
Color Acrylic Sheet
-
colour:
-
Black, White, Clear, Red, Orange, etc.
-
raw material:
-
100% virgin Lucite material acrylic sheet
-
Density:
-
1.2g/cm3
-
Weather Resistance:
-
Withstand sunlight for long duration against discoloration, anti-UV
-
Insulation:
-
Higher resistivity to be ideal insulator
-
certificate:
-
CE approved
-
Film on both sides:
-
PE or craft paper covered acrylic sheets
Quick Details
-
Processing Service:
-
Cutting, Moulding
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Shuohang
-
Model Number:
-
Color Acrylic Sheet
-
Thickness:
-
1.8-300mm, 1-50mm
-
Size:
-
1250*1850mm and so on, 1220*2440mm, 1220*1830mm or customized
-
Product name:
-
Color Acrylic Sheet
-
colour:
-
Black, White, Clear, Red, Orange, etc.
-
raw material:
-
100% virgin Lucite material acrylic sheet
-
Density:
-
1.2g/cm3
-
Weather Resistance:
-
Withstand sunlight for long duration against discoloration, anti-UV
-
Insulation:
-
Higher resistivity to be ideal insulator
-
certificate:
-
CE approved
-
Film on both sides:
-
PE or craft paper covered acrylic sheets
Products Description
|
standard size
|
1220*2440mm,1220*1830mm,2000*3000mm
|
|
edge included size
|
1260*2480mm,1260*1880mm,2050*3010mm
|
|
thickness
|
1.8mm-30mm
|
|
color
|
red, white,yellow,orange,black,etc, as the client's request
|
|
surface
|
frosted,smooth, mirror,double side mirror
|
|
inside
|
shining cotton gold,silver or other color and other thing like leaf
|
|
tolerance
|
0.1mm-0.2mm,according to the thickness of the sheet
|
|
cutting service
|
we can cut the sheet into any size to meet your demand
|
|
Our popular sizes
|
|
|
|
|
|
|
||||||
|
With Edge (mm)
|
1250×1850
|
1250×2450
|
1050×2050
|
1850×2450
|
2090×3090
|
1550×3050
|
||||||
|
Without Edge (mm)
|
1220×1830
|
1220×2440
|
1020×2020
|
1820×2420
|
2050×3050
|
1500×3000
|
||||||
|
Note: Total we have up to 30 different sizes, contact us for more detail.
|
|
|
|
|
|
|
||||||
|
Thickness: 1.8-30mm
|
|
|
|
|
|
|
||||||
|
Physical Property of Cast Acrylic sheet
|
|
|
|
|||
|
|
PROPERTY
|
UNIT
|
VALUE
|
|||
|
MECHANICAL
|
Specific Gravity
|
—
|
1.19-1.2
|
|||
|
|
Roswell Hardness
|
kg/cm 2
|
M-100
|
|||
|
|
Shear Strength
|
kg/cm 2
|
630
|
|||
|
|
Flexural Strength
|
kg/cm 2
|
1050
|
|||
|
|
Tensile Strength
|
kg/cm 2
|
760
|
|||
|
|
Compressive Strength
|
kg/cm 2
|
1260
|
|||
|
ELECTRICAL
|
Didlectic Strength
|
Kv/mm
|
20
|
|||
|
|
Surface Resistivity
|
Ohm
|
> 10 16
|
|||
|
OPTICAL
|
Light Transmittance
|
%
|
93
|
|||
|
|
Refractive Index
|
—
|
|
|||
|
THERMAL
|
Specific Heat
|
Cal/gr℃
|
0.35
|
|||
|
|
Coefficient of Thermal Cortductivily
|
Cal/xee/cm/℃/cm
|
|
|||
|
|
Hot Forming Temp
|
℃
|
140-180
|
|||
|
|
Hot Defomation Temp
|
℃
|
100
|
|||
|
|
Thermal Expansion Coefficient
|
Cmfcm/V
|
6×10-5
|
|||
|
MISCELLANEOUS
|
Water Absorption(24Hrs)
|
%
|
0.3
|
|||
|
|
Teste
|
%
|
None
|
|||
|
|
Odor
|
|
|
|||
Product packaging
1.one pc acrylic sheetpacking: covered with craft paper or PE film on double sides ,the covered film without any our compoany sign.
2.with pallet Bulk cargo packing: 2 tons per pallet, use wooden pallets and iron pallets on bottom, with packaging film packages all around ensure transportation security.
3.Full container load packing: 20-23 tons(about 3000pcs) of a 20 foot container with 10 -12pallets .
2.with pallet Bulk cargo packing: 2 tons per pallet, use wooden pallets and iron pallets on bottom, with packaging film packages all around ensure transportation security.
3.Full container load packing: 20-23 tons(about 3000pcs) of a 20 foot container with 10 -12pallets .
