Quick Details
-
Use:
-
Warehouse Rack, warehouse storage
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
ESWIRES
-
Model Number:
-
ES01-40
-
Depth:
-
Customerization
-
Weight Capacity:
-
300-1200 kg
-
Width:
-
Customerization
-
Height:
-
Customerization
-
Dimensions:
-
1100x880 mm
-
Mesh size:
-
50x50/50x100/50x125 mm and Customer Size
-
Wire diameter:
-
4-6 mm or customized
-
Channel thickness:
-
1.2/ 1.5/ 1.8/ 2 mm
-
Finish:
-
Zinc/hot dip galvanized/powder coating
-
Advantages:
-
Flexibility, versatility
-
Waterfall:
-
Up-turned, flat flush, inside waterfull
-
Channel type:
-
Flared channel, U channel, inverted U channel
-
Beam:
-
Suitable for box beam or step beam
-
General Use:
-
Storage, Garage, Supermarket, Showroom, Exhibition et
Quick Details
-
Type:
-
Plate Type
-
Material:
-
Steel
-
Feature:
-
Corrosion Protection
-
Use:
-
Warehouse Rack, warehouse storage
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
ESWIRES
-
Model Number:
-
ES01-40
-
Depth:
-
Customerization
-
Weight Capacity:
-
300-1200 kg
-
Width:
-
Customerization
-
Height:
-
Customerization
-
Dimensions:
-
1100x880 mm
-
Mesh size:
-
50x50/50x100/50x125 mm and Customer Size
-
Wire diameter:
-
4-6 mm or customized
-
Channel thickness:
-
1.2/ 1.5/ 1.8/ 2 mm
-
Finish:
-
Zinc/hot dip galvanized/powder coating
-
Advantages:
-
Flexibility, versatility
-
Waterfall:
-
Up-turned, flat flush, inside waterfull
-
Channel type:
-
Flared channel, U channel, inverted U channel
-
Beam:
-
Suitable for box beam or step beam
-
General Use:
-
Storage, Garage, Supermarket, Showroom, Exhibition et
Wire Decking for Pallet Racks Used in Material Handling Industry
As a shelf offering an alternative to timber decking and solid steel panel solutions
| Euro Sizes | |||
| A. Loading capacity 300kg | B. Loading capacity 500kg | C. Loading capacity 800kg | D. Loading capacity 1000kg |
| Mesh 50×150 mm | Mesh 50×125 mm | Mesh 50×100 mm | Mesh 50×100 mm |
| Dim (D×W) (mm) | Dim (D×W) (mm) | Dim (D×W) (mm) | Dim (D×W) (mm) |
| 800×880 | 1000×880 | 1000×880 | 900×1340 |
| 1100×880 | 1050×880 | 1050×880 | 1050×1340 |
| 600×880 | 1100×880 | 1100×880 | 1100×1340 |
| 1050×880 | 1000×1090 | 800×1340 | |
| American Sizes | ||
| Standard U-channel | Pallet Deck | |
| Dim (D×W) (inch) | Dim (D×W) (inch) | |
| 24"×46" | 42"×46" | 24"×46" |
| 30"×46" | 42"×52" | 36"×46" |
| 36"×34" | 42"×58" | 36"×52" |
| 36"×46" | 48"×34" | 42"×46" |
| 36"×52" | 48"×46" | 42"×52" |
| 36"×58" | 48"×52" | 44"×46" |
| 42"×34" | 48"×58" | 48"×46" |
Wire decking are widely used on box beam pallet racks. The two ends of the "U" shape supports are flared flat, and easy to install onto the box beam surface with the waterfalls over the beaming face to fasten the wire decking. It protects the operators and products, providing heavy load capacity. The F-style wire mesh decking can also be used on C-shape, I-shape and step beam pallet racks.
Wire mesh decking
for shelving is commonly used as a safety measure on selective pallet racks to prevent pallets or the products stored on them from falling through the rack structure.
It comes in various thicknesses and meshes dimensions. Wire mesh construction also allows for easy identification of shelf contents and prevents dirt and other debris from accumulating on the shelves because of the holes in the mesh.
Currently, our wire decking is widely exported to the US, UK, France & Australia .
Custom style is welcome. Contact us now to get a FREE sample for the test!
More accessories for warehouse shelves, such as wire shelf dividers, back panels, back mesh, flat mesh, etc.
In order to prevent damage, the high-quality carton and plastic film are used for packing, and the wooden pallet with a forklift pocket is put under the carton at the same time.
Besides, we can make the package as our customer's requirement.
We have enough stock for nominal specification products to satisfy our customer's urgent needs. For our very important persons , we can offer our warehouse to store the mass order until the customers issue us to ship.
