Quick Details
-
Type of gasifier (3):
-
downdraft fixed bed gasifier
-
Type of gas cleaning:
-
Dry type gas cleaning system
-
Frequency:
-
50/60 Hz
-
Rated Voltage (v):
-
220/400/440/6300/6600/11000/13800
-
Rated Power:
-
50-2000 kw
-
Biomass moisture(%):
-
16%(wet base)
-
Biomass size:
-
10-80mm
-
Heat value of gas:
-
1100-1300 kcal/Nm3
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Type of gasifier (1):
-
circulating fluidized bed gasifier
-
Type of gasifier (2):
-
updraft fixed bed gasifier
-
Type of gasifier (3):
-
downdraft fixed bed gasifier
-
Type of gas cleaning:
-
Dry type gas cleaning system
-
Frequency:
-
50/60 Hz
-
Rated Voltage (v):
-
220/400/440/6300/6600/11000/13800
-
Rated Power:
-
50-2000 kw
-
Biomass moisture(%):
-
16%(wet base)
-
Biomass size:
-
10-80mm
-
Heat value of gas:
-
1100-1300 kcal/Nm3
| Technical Specification of Biomass Gasification Power Generation System | |||||||||
| Rated Power(KW) | 50 | 100 | 200 | 300 | 400 | 500 | 600 | 800 | 1000 |
| Rated Frequency | 50/60HZ | ||||||||
| Rated Voltage(V) | 220/400/440/6300/6600/11000/13800 | ||||||||
| Gasifier Type | Circulating fluidized bed gasifier / Updraft fixed bed gasifier / Downdraft fixed bed gasifier / Twin-fire Fixed Bed Gasifier | ||||||||
|
Biomass Moisture Requirement |
≤20%(Wet Basis) / ≤20%-35%(Wet Basis) / ≤16%(Wet Basis) / ≤20%(Wet Basis) | ||||||||
|
Biomass Size Requirement |
≤10mm / Diameter 20mm-80mm; Length 10mm-80mm / ≤10mm / Diameter 20mm-80mm; Length 10mm-80mm | ||||||||
|
Biomass Consumption (Kg/Hr) |
50-100 | 100-200 | 200-400 | 300-600 | 400-800 | 500-1000 | 600-1200 | 800-1600 | 1000-2000 |
| Gas Production(Nm³/h) | 125-150 | 250-300 | 500-600 | 750-900 | 1000-1200 | 1250-1500 | 1500-1800 | 2000-2400 | 2500-3000 |
| Ash Discharge Type | Dry Ash Type/Wet Ash Type | ||||||||
| Type of Gas Purification | Dry Type Gas Purification System | ||||||||
| Heat Value of Gas | 1100-1300Kcal/Nm³ | ||||||||
| Model of Genset | 50GFLS | 100GFLS | 100GFLS | 300GFLS | 400GFLS | 500GFLS | 300GFLS | 400GFLS | 1000GFLS |
| Qty of Genset | 1 Set | 1 Set | 2 Sets | 1 Set | 1 Set | 1 Set | 2 Sets | 2 Sets | 1 Set |
Welcome to Powermaxgasifiers.com !
Powermax is a green and clean energy company. Powermax has a long experience in producing and supplying environmentally friendly and high performing gasification systems and gas generator sets. We are specialized in biomass, coal and waste gasification to energy systems and have a company history of30 years. Powermax have since the start of 1986 been specialized in biomass gasification power plants.Our. gasification energy systems can convert various types of biomass, waste or coal into: electricity,process steam, drying, industrial heating, district heating and etc. Powermax has its own Development,Design, Construction and Project Management Departments.. We have our own in-house gasifiers, gas purification systems and gas generator sets production facilities in China. All our gasification designs benefit from more than 100 reference installations worldwide.
