Quick Details
-
Model Number:
-
SCPSD-600-14-15
-
Max. Current:
-
contact me
-
Max. Working Pressure:
-
contact me
-
Product name:
-
Electronic pressure switch
-
Certification:
-
ISO9001
Quick Details
-
Max. Voltage:
-
contact me
-
Place of Origin:
-
Germany
-
Brand Name:
-
Parker
-
Model Number:
-
SCPSD-600-14-15
-
Max. Current:
-
contact me
-
Max. Working Pressure:
-
contact me
-
Product name:
-
Electronic pressure switch
-
Certification:
-
ISO9001
Products Description
|
Product name
|
Electronic pressure switch
|
Features
SCPSD- 004 010 016 060 100 250 400 600
Pressure range PN (bar) - 1... 4 - 1... 10 - 1... 160... 600... 100... 250... 400... 600
Overload pressure PN (bar) 10 20 40 120 200 500 800 1200
Burst pressure PN (bar) 12 25 50 550 800 1200 1700 2200
Display accuracy (bar) 0.01 0.01 0.01 0.10.1
The minimum value that can be set between SP and RSP
Difference (sp-rsp)
0.08 0.05 0.09 0.3 0.6 2 3 3
Ceramic materials for measuring elements
4404 stainless steel;
Al 2O 3 ceramic; NBR
DMS film
Stainless steel 1.4404; 1.4542 parts in contact with media
Input quantity
Reliability period ≥ 100 million times
Scanning speed ≥ 5 ms
Connection thread G1 / 4 BSPP;
Ed soft seal NBR*
(DIN 3852 T2, type X);
Ed (din3852 T11, type E)
Tightening torque 35 nm
Medium temperature range - 20... + 85 ℃
It weighs about 300 G
Output
Typical accuracy: ± 0.5 % FS ;
maximum: ± 1 % FS
Typical temperature drift characteristics are as follows ± 0.02 % FS/ ° K (at
-20 to + 85 ℃)
maximum: ± 0.03 % FS/ ° K
Long term stability ± 0.2 % FS/a
Repeatability ± 0.25 % FS
Typical switching point accuracy: ± 0.5 % FS ；
maximum: ± 1 % FS
Typical display accuracy: ± 0.5 % FS; Value: ± one
maximum: ± 1 % FS; Value: ± one
response speed
Switch output ≤ 10 ms
Analog output ≤ 10 ms
Circuit connection
Supply voltage V + 15... 30 VDC nominal
24 VDC; Protection class 3
Circuit connection M12x1; 4 cores; 5 cores;
With gold-plated contacts.
Electrical socket connector in accordance with
DIN EN 175301-803 type A
(old version din43650)
Short circuit protection is
Reverse polarity protection is
Overvoltage protection is
Current consumption < 100 Ma
Shell
Rotatable temperature: 290 ℃
Material: Z410 die casting zinc alloy; spray
Foil material polyester
Display 4-bit 7-segment LED;
Red; Digital height 9 mm
Protection grade IP67, DIN EN 60529;
The socket is IP65
DIN EN 175301-803 type A
(old version din43650)
