- Product Details
- {{item.text}}
Quick Details
-
Network:
-
NC
-
Product name:
-
Copper material shell magnetic contact sensor for wooden door
-
Working voltage:
-
Max DC 100V
-
Working current:
-
Max 0.5A
-
Power consumption:
-
10W
-
Induction gap:
-
20~30mm
-
Application:
-
Door access control system and burglar alarm system
-
Dimension:
-
Reed part:11(diameter)*29mm Magnetic part:11(diameter)*17mm
-
Material:
-
Plastic housing+ PCB board+ Reed switch
-
Weight:
-
33g per pair
-
Warranty:
-
2 years and welcome OEM
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SMQT
-
Model Number:
-
EB-141
-
Network:
-
NC
-
Product name:
-
Copper material shell magnetic contact sensor for wooden door
-
Working voltage:
-
Max DC 100V
-
Working current:
-
Max 0.5A
-
Power consumption:
-
10W
-
Induction gap:
-
20~30mm
-
Application:
-
Door access control system and burglar alarm system
-
Dimension:
-
Reed part:11(diameter)*29mm Magnetic part:11(diameter)*17mm
-
Material:
-
Plastic housing+ PCB board+ Reed switch
-
Weight:
-
33g per pair
-
Warranty:
-
2 years and welcome OEM
Wire Embedded Terminal Block No/nc Metal Copper Grey Color Magnetic Contact Proximity Switch For Door Window Alarm
SMQT, 13 YEARS gold supplier in Alibaba platform
EB-141'S MAIN PARAMETER
| Product Name: | Copper material shell magnetic contact sensor for wooden door |
| Model number: | EB-141 |
| Working voltage: | Max DC 100 |
| Working current: | Max 0.5A |
| Power consumption: | 10W |
| Interface port: | NC/COM |
| Induction gap: | 20~30mm |
| Size: |
Reed part:10(Diameter)*2.9(H)(mm) Magnet part: 10(Diameter) *2.9(H)(mm) |
| Insatallation way: | Embedded installation |
| Suitable for: | All kinds of door access control system and burglar alarm system |
| Material: | Copper housing+ PCB board+Reed switch |
| Housing color: | White/Brown(optional) |
| Weight: |
Unit:33 10 pairs per bag, per bag weight 330g |
| Warranty: | 2 years warranty |
| OEM: | Welcome OEM |
EB-141'S FEATURE SHOW
