Quick Details
-
Table Size:
-
2.4*0.8*2.1
-
Weight:
-
4560 kg
-
Marketing Type:
-
New Product 2022
-
Overall size:
-
2.475 * 0.81 *2.158m
-
Safe working load:
-
230kg
-
Certificate:
-
CE ISO
-
Maximum number of passengers:
-
2
-
Lifting speed:
-
6-9m/min
-
Turning radius:
-
0.15/2.85
-
wheelbase:
-
2.26m
-
Battery:
-
lead acid
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
LTMG
-
Table Size:
-
2.4*0.8*2.1
-
Weight:
-
4560 kg
-
Marketing Type:
-
New Product 2022
-
Overall size:
-
2.475 * 0.81 *2.158m
-
Safe working load:
-
230kg
-
Certificate:
-
CE ISO
-
Maximum number of passengers:
-
2
-
Lifting speed:
-
6-9m/min
-
Turning radius:
-
0.15/2.85
-
wheelbase:
-
2.26m
-
Battery:
-
lead acid
Product Description
Specification
|
Model
|
LTWP0810
|
LTWP1012
|
LTWP1214
|
|
Working Height Maxdmum
|
10.00m
|
12.00m
|
14.00m
|
|
Platform Height Maximum
|
8.00m
|
10.00m
|
12.00m
|
|
Safe working load
|
230kg
|
230kg
|
230kg
|
|
Extended platlorm safe working load
|
100kg
|
100kg
|
100kg
|
|
Working platform size (L*w*h)
|
2.26x0.81 x 1.1m
|
2.26x1.13x1.1m
|
2.26x1.13x1.1m
|
|
Overall size
|
2.475x0.81 x 2.286m
|
2.475x1.15x2.414m
|
2.475x1.15 x 2.542m
|
|
Overall size
|
2.475x0.81 x 1.836m
|
2.475 x1.15 x1.964m
|
2.475 x 1.15 x 2.094m
|
|
Length extension deck
|
0.9m
|
0.9m
|
0.9m
|
|
Ground clearance-center
|
0.1/0.02m
|
0.1/0.02m
|
0.1/0.02m
|
|
Wheelbase
|
1.89m
|
1.89m
|
1.89m
|
|
Turning radius (inner/ outer wheel)
|
0/2.1 m
|
012.2m
|
0/2.2m
|
|
Lifting / driving motor
|
24V/4.5kw
|
24V/4.5kw
|
24V/4.5kw
|
|
Lifting speed
|
3-5m/min
|
3-5m/min
|
3-5m/min
|
|
The machine speed (folded state)
|
3.5km/h
|
3.5km/h
|
3.5km/h
|
|
Machine travel speed (lifting state)
|
0.8km/h
|
0.8km/h
|
0.8km/h
|
|
Battery
|
4x6V/225ah
|
4x6V/225ah
|
4x6V/245ah
|
|
Charger
|
24V/25A
|
24V/25A
|
24V/25A
|
|
Max Climb Capability
|
25%
|
25%
|
25%
|
|
Maximum allowable working angle
|
1.5° /3°
|
2。/3°
|
1.5° 13°
|
|
yre
|
0381x127mm
|
0381 x 127mm
|
0381 x 127mm
|
|
Weight
|
1845kg
|
2300kg
|
2460kg
|
After -Sales Service
LTMG always treat after-sale service as important as sale. Nowadays more than 50 agents around the world can supply LTMG professional after-sale service.
All the product of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please check our website and product certificate.
All the product of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please check our website and product certificate.
