Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Contrastech
-
Model Number:
-
Mars
-
Application:
-
monitor flame propagation, Billiards ball tracking, Golf simulator
-
Sensor (ON Semiconductor):
-
IMX287/PYTHON480
-
Sensor Technology:
-
CMOS, Global
-
Sensor Size (optical):
-
1/2.9'' 1/3.6"
-
Pixel Size (μm):
-
4.8 * 4.8/6.9*6.9
-
Resolution (H*V):
-
720*540/800*600
-
Frame Rate (Max. fps):
-
815
-
Interface:
-
GigE, PoE
-
Lens Mount:
-
C-Mount
-
Power Input:
-
DC6~24V
-
Housing Size (L*W*H):
-
42.0 mm *29.0 mm * 29.0 mm (88g)
Quick Details
-
Special Features:
-
Motion Detection, High speed
-
Function:
-
NIGHT VISION
-
Customized support:
-
Online technical support, Customized logo, OEM, ODM
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Contrastech
-
Model Number:
-
Mars
-
Application:
-
monitor flame propagation, Billiards ball tracking, Golf simulator
-
Sensor (ON Semiconductor):
-
IMX287/PYTHON480
-
Sensor Technology:
-
CMOS, Global
-
Sensor Size (optical):
-
1/2.9'' 1/3.6"
-
Pixel Size (μm):
-
4.8 * 4.8/6.9*6.9
-
Resolution (H*V):
-
720*540/800*600
-
Frame Rate (Max. fps):
-
815
-
Interface:
-
GigE, PoE
-
Lens Mount:
-
C-Mount
-
Power Input:
-
DC6~24V
-
Housing Size (L*W*H):
-
42.0 mm *29.0 mm * 29.0 mm (88g)
Note:
"UM/UC" means USB3.0 Mono/Color
"GM/GC" means GigE Mono/Color
"CM/CC" means CameraLink Mono/Color
"XM/XC" means CoaXPress Mono/Color
|
Model
|
Sensor
|
Frame Rate
|
Resolution
|
Interface
|
Image Color
|
|
Mars720-300gm
|
IMX287
|
300FPS
|
720*540
|
Gige
|
Mono
|
|
Mars720-300gc
|
IMX287
|
300FPS
|
720*540
|
Gige
|
Color
|
|
Mars800-545um
|
PYTHON480
|
545FPS
|
800*600
|
USB3.0
|
Mono
|
|
Mars800-545uc
|
PYTHON480
|
545FPS
|
800*600
|
USB3.0
|
Color
|
|
Shutter Type
|
Global
|
|
Lens Mount
|
C-mount
|
|
Image Format
|
Monochrome:Mono8/10/10p/12/12p
Color:Mono 8/10/12,Bayer RG 8/10/10p/12/12p,YUV422Packed,YUV422_YUYV_Packed,RGB 8,BGR 8
|
|
Operating System
|
Windows，Linux
|
|
Driver
|
Mars Series Camera Secondary Development Kit（iCentral）or Third-party Software meeting with USB3 Vision Protocol
|
|
Synchronization
|
● Soft Trigger
● Hardware Trigger ● Free Run |
|
Conformity
|
USB3 Vision and GenICam
|
As one high-tech enterprise Hangzhou Contrastech Co., Ltd. specializes in providing professional machine vision software, hardware and equipments. Contrastech has been researching and developing machine vision applications, major products including industrial camera, scientific standard camera, high definition frame grabber card, industrial FA lenses, telecentric lens, machine vision lightings and image processing software. The Engineering Dept. of Contrastech has a lot of mature and successful machine vision solutions which based on automatic industrial inspection, high precision measuring and the module distinguishing.
