anti-aging aluminum pontoon folding boat gangway dock floats for sale

Material of Pontoon Buoy

100% high molecular weight and high density synthetic material HDPE

Blue, orange, yellow,red and so on

QB 1557-1992

Diagonal tensile strength

GB/T 1040.1-2006

Compressive strength

GB/T 8813-2008

Tensile strength

ASTM D638-2014

Impact strength

ASTM D256-2010

ROHS tests

The raw materials do not contain six chemicals including lead,

mercury, cadmium, hexavalent chromium, polybrominated biphenyl

and polybrominated diphenyl ether, making it more conducive to

human health and environmental protection.

Pontoon Steel Frame

The main steel frame structure of the pontoon bridge adopts galvanized steel

structure, and the material conforms to the national standard (GB700-88)

Technical Conditions for Ordinary Carbon Steel.

Pontoon Decking

Float Pontoon Decking Panels are made of high-resistance bamboo and

wood panels with high density, good toughness, high strength, strong and

durable, not easy to deform, smooth texture, soft color, elegant and

generous, and are environmentally friendly and green products.

As the average water depth at the site is 2-3 meters, the water level is stable

all the year round and there are no waves, so the steel pipe pile is used

for positioning and will not move due to external force.

The approach bridge shall be made of aluminum alloy or galvanized steel

structure and laid with bamboo and wood panels with a load of 200 kg/m2

or more. The shore is connected with a concrete base (bank protection)

by a hinged seat. Nylon roller sets are welded at the bottom of one end of

the floating bridge.

First, connect the individual buoys through earrings.

A single buoy forms a plane.

Place the short connecting bolt into the concave hole in the plane at an angle of 45 degrees.

Use a special tool torque wrench to install the buoy.

Turn the torque wrench counterclockwise for 45 degrees to connect the individual buoys.

Complete the installation.

Q1. What is life expectancy for the product?

A: Life expectancy: 4-5 years.

Q2. Price per square meter including all required accessories or not?

A: We will quoted the price by SQM including all required accessories. They are easy to be

assemble or disassemble.

Q3. Do they need to be dismembered and stored in winter time?

A: The material do not need to be dismembered and stored in winter time, they are anti-freezing.

Q4. Do the products have Gangway?

A: Yes, we can supply all the parts for pontoon according to your request.

Q5. Are you able to tie wooden board on the surface?

A: Yes, we do. We will send wooden board and related accessories. They are easy to be assemble

or disassemble.
