Quick Details
-
Brand Name:
-
DEWO
-
Model Number:
-
DV-16-A01-MM2-200E, DV-16-A01-MM2-200E
-
Max. Current:
-
20A
-
Operating Temperature:
-
40T125
-
Protection Level:
-
IP40
-
Item:
-
Cash drawer toggle kw11-3z 20a 250v mini t125 5e4 micro switches
-
Rating:
-
16A 125/250VAC
-
Electrical Life:
-
50,000cycles
-
Mechanical Life:
-
1,000,000cycles
-
Autuator:
-
button/lever
-
Terminal Type:
-
solder/PCB/quick connect terminal
-
Circuit:
-
SPDT/SPST-NC/SPST-NO
-
Operating Force:
-
0.5~2.5N
-
Approval:
-
UL, KC, ENEC, CQC, CB, CUL
Quick Details
-
Whether the smart:
-
NO
-
Max. Voltage:
-
250V
-
Place of Origin:
-
China
-
Brand Name:
-
DEWO
-
Model Number:
-
DV-16-A01-MM2-200E, DV-16-A01-MM2-200E
-
Max. Current:
-
20A
-
Operating Temperature:
-
40T125
-
Protection Level:
-
IP40
-
Item:
-
Cash drawer toggle kw11-3z 20a 250v mini t125 5e4 micro switches
-
Rating:
-
16A 125/250VAC
-
Electrical Life:
-
50,000cycles
-
Mechanical Life:
-
1,000,000cycles
-
Autuator:
-
button/lever
-
Terminal Type:
-
solder/PCB/quick connect terminal
-
Circuit:
-
SPDT/SPST-NC/SPST-NO
-
Operating Force:
-
0.5~2.5N
-
Approval:
-
UL, KC, ENEC, CQC, CB, CUL
Product Description
Specification
|
item
|
value
|
|
Certification
|
UL CUL ENEC CQC CB KC CE
|
|
Place of Origin
|
GUA
|
|
Brand Name
|
DEWO
|
|
Model Number
|
DV-16-A01-MM2-200E
|
|
Max. Current
|
20A
|
|
Max. Voltage
|
250V
|
|
Operating Temperature
|
40T125
|
|
Protection Level
|
IP40
|
|
Item
|
Cash drawer toggle kw11-3z 20a 250v mini t125 5e4 micro switches
|
|
Model Number
|
DV-16-A01-MM2-200E
|
|
Rating
|
16A 125/250VAC
|
|
Electrical Life
|
50,000cycles
|
|
Mechanical Life
|
1,000,000cycles
|
|
Autuator
|
button/lever
|
|
Terminal Type
|
solder/PCB/quick connect terminal
|
|
Circuit
|
SPDT/SPST-NC/SPST-NO
|
|
Operating Force
|
0.5~2.5N
|
|
Approval
|
UL, KC, ENEC, CQC, CB, CUL
|
Packing & Delivery
micro switch IS 500pcs micro switch per blister box, 10 boxes per carton(36.5*24.5*24.5cm)and Transport by express, by air, by sea, by car or by train is as your requested.
