Quick Details
-
Model Number:
-
JY0425
-
Product name:
-
8-400 mesh plain weave brass wire mesh screen
-
Color:
-
Golden Yellow Brass
-
Mesh Size:
-
customizable
-
Standard length:
-
30m per roll or as required
-
Width:
-
0.6-1.5m or custom
-
Wire diameter:
-
0.05mm,0.04mm,0.03mm
-
Special specification:
-
Can be customized
Quick Details
-
Material:
-
Brass
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
JIAN YANG
-
Model Number:
-
JY0425
-
Product name:
-
8-400 mesh plain weave brass wire mesh screen
-
Color:
-
Golden Yellow Brass
-
Mesh Size:
-
customizable
-
Standard length:
-
30m per roll or as required
-
Width:
-
0.6-1.5m or custom
-
Wire diameter:
-
0.05mm,0.04mm,0.03mm
-
Special specification:
-
Can be customized
Products Description
What's Brass Wire Mesh ?
Brass mesh cloth is made of brass wire. The material of brass wire could be divided into 65 brass, 70 brass and 80 brass. Warp and weft wires normally have the same diameter. Brass mesh and brass wire cloth have better abrasion and corrosion resistance, better tensile strength, lower electricity and heat conductivity compared with copper mesh cloth. They are widely used in sieving and filtering granule, powder, porcelain clay and glass, chinaware printing, grain, filtering liquid and gas, also used as decorative mesh.
Brass wire mesh features：
1.Beautiful appearance shows unique effects；
2.Flexible and can be molded into different shapes；
3.Durable and fire-resistant；
4.Light weight and thin；
5.High density；
6.Recyclable and has a long service life.
Application：
1.Can be made into a variety of filters filter, screen some liquid, air and powder, China clay, particles；
2.As insect screens；
3.Decorative ceiling, lampshades, stairs, facades；
4.As a hotel, exhibition hall and other advanced places of space partition；
5.Can be designed into artworks.
Brass
is an alloy that is comprised of copper and zinc, and, like copper, brass is soft and malleable and is attacked by ammonia and similar salts.
As a wire mesh, the most commonly available brass woven wire mesh is referred to as “270 yellow brass” and has a chemical composition of approximately 65% copper, 35% zinc. “260 high brass”, which consists of 70% copper and 30% zinc is also a popular in the mesh industry, particularly on custom manufactured items.
|
Product Name
|
Brass wire mesh
|
|
|
|
|
Wire diameter
|
0.05--2.03mm
|
|
|
|
|
Length
|
1--30m
|
|
|
|
|
Technique
|
woven
|
|
|
|
|
Material type
|
Plain woven,Twill woven,Dutch woven etc
|
|
|
|
|
Mesh count
|
1-200 mesh
|
|
|
|
|
Mesh
|
Aperture(mm)
|
Wire Diameter
|
Effective (%)
|
Weight (Kg/m2)
|
|
Mesh 3
|
6.27
|
2.2
|
62
|
7
|
|
Mesh 5
|
4.36
|
0.711
|
76
|
1.6
|
|
Mesh 6
|
3.52
|
0.711
|
63
|
1.6
|
|
Mesh 8
|
2.5
|
0.559
|
67
|
1.5
|
|
Mesh 10
|
2.08
|
0.46
|
67
|
1.1
|
|
Mesh 12
|
1.74
|
0.457
|
68
|
1.4
|
|
Mesh 14
|
1.36
|
0.46
|
57
|
1.4
|
|
Mesh 16
|
1.21
|
0.376
|
55
|
1.2
|
|
Mesh 18
|
1.1
|
0.315
|
60
|
0.85
|
|
Mesh 20
|
0.95
|
0.315
|
58
|
0.95
|
|
Mesh 30
|
0.67
|
0.274
|
55
|
0.85
|
|
Mesh 40
|
0.44
|
0.152
|
46
|
0.58
|
|
Mesh 50
|
0.36
|
0.152
|
50
|
0.45
|
|
Mesh 60
|
0.3
|
0.122
|
50
|
0.45
|
|
Mesh 80
|
0.198
|
0.12
|
44
|
0.58
|
|
Mesh 100
|
0.154
|
0.1
|
37
|
0.5
|
|
Mesh 120
|
0.13
|
0.081
|
40
|
0.39
|
|
Mesh 150
|
0.097
|
0.61
|
32
|
0.3
|
|
Mesh 200
|
0.086
|
0.041
|
46
|
0.17
|
Details Images
weaving process
Weave Styles
