- Product Details
- {{item.text}}
Quick Details
-
Color:
-
Transparent
-
Panel Size:
-
384 x 816mm
-
Place of Origin:
-
Shanghai, China
-
Model Number:
-
LED Screen Film
-
Brightness:
-
2000/4000
-
pixel density:
-
27777
-
Color Depth:
-
16bit
-
Lifespan (hours):
-
10000 hours
-
View Angle（H/V）:
-
140
-
Product name:
-
mavi film seks sticky flexible crystal layar flexible thin film LED
-
Size:
-
width: 400mm height: /1000mm
-
Thickness:
-
2mm
-
Max Size:
-
400*1000
-
MOQ:
-
1 pcs
-
Keyword:
-
flexible led display transparent ekran FILM
Quick Details
-
Application:
-
Indoor
-
Type:
-
LED
-
Brand Name:
-
ValuesGlass
-
Color:
-
Transparent
-
Panel Size:
-
384 x 816mm
-
Place of Origin:
-
Shanghai, China
-
Model Number:
-
LED Screen Film
-
Brightness:
-
2000/4000
-
pixel density:
-
27777
-
Color Depth:
-
16bit
-
Lifespan (hours):
-
10000 hours
-
View Angle（H/V）:
-
140
-
Product name:
-
mavi film seks sticky flexible crystal layar flexible thin film LED
-
Size:
-
width: 400mm height: /1000mm
-
Thickness:
-
2mm
-
Max Size:
-
400*1000
-
MOQ:
-
1 pcs
-
Keyword:
-
flexible led display transparent ekran FILM
Product Parameters
Application
Picture Display
Specification
|
Model
|
P6
|
P6.25
|
P8
|
P10
|
P15
|
P20
|
|
Module size (mm)
|
816*384
|
1000*400
|
1000*400
|
1000*400
|
990*390
|
1000*400
|
|
LED light
|
REE1515
|
REE1515
|
REE1515
|
REE1515
|
REE2022
|
REE2022
|
|
Pixel composition
|
R1G1B1
|
R1G1B1
|
R1G1B1
|
R1G1B1
|
R1G1B1
|
R1G1B1
|
|
Pixel spacing (mm)
|
6*6
|
6.25*6.25
|
8*8
|
10*10
|
15*15
|
20*20
|
|
Module pixel
|
136*64=8704
|
160*40=6400
|
125*50=6250
|
100*40=4000
|
66*26=1716
|
50*20=1000
|
|
Pixel/m2
|
27777
|
25600
|
16500
|
10000
|
6625
|
2500
|
|
Brightness
|
2000/4000
|
2000/4000
|
2000/4000
|
2000/4000
|
2000/4000
|
2000/4000
|
|
Permeability
|
90%
|
90%
|
92%
|
94%
|
94%
|
95%
|
|
Angle of view °
|
160
|
160
|
160
|
160
|
160
|
160
|
|
Input voltage
|
AC110-240V50/ 60Hz
|
AC110-240V50/ 60Hz
|
AC110-240V50/ 60Hz
|
AC110-240V50/ 60Hz
|
AC110-240V50/ 60Hz
|
AC110-240V50/ 60Hz
|
|
Peak power
|
400w/㎡
|
600w/㎡
|
400w/㎡
|
400w/㎡
|
400w/㎡
|
400w/㎡
|
|
Average power
|
200w/㎡
|
200w/㎡
|
200w/㎡
|
200w/㎡
|
200w/㎡
|
200w/㎡
|
|
Work environment
|
Temperature
- 20~55
Humidity
10-90%
|
Temperature
- 20~55
Humidity
10-90%
|
Temperature
- 20~55
Humidity
10-90%
|
Temperature
- 20~55 Humidity
10-90%
|
Temperature
- 20~55
Humidity
10-90%
|
Temperature
- 20~55
Humidity
10-90%
|
|
Weight
|
1.3kg
|
1.3kg
|
1.3kg
|
1.3kg
|
1.3kg
|
1.3kg
|
|
Thickness
|
2.5mm
|
2.5mm
|
2.5mm
|
2.5mm
|
2.5mm
|
2.5mm
|
|
Drive mode
|
static state
|
static state
|
static state
|
static state
|
static state
|
static state
|
|
Control system
|
Nova/Colorlight
|
Nova/Colorlight
|
Nova/Colorlight
|
Nova/Colorlight
|
Nova/Colorlight
|
Nova/Colorlight
|
|
Typical value of life
|
100000H
|
100000H
|
100000H
|
100000H
|
100000H
|
100000H
|
|
Grayscale level
|
16bit
|
16bit
|
16bit
|
16bit
|
16bit
|
16bit
|
|
Refresh rate
|
3840Hz
|
3840 Hz
|
3840 Hz
|
3840Hz
|
3840 Hz
|
3840 Hz
|
