Quick Details
-
Warranty(Year):
-
1-Year
-
Lamp Luminous Efficiency(lm/w):
-
1800
-
Color Rendering Index(Ra):
-
85
-
Product Weight（kg）:
-
10
-
Input Voltage(V):
-
AC120V/230V, 60/50Hz
-
Lamp Luminous Flux(lm):
-
100
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-15 - 45
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Grace
-
Emitting Color:
-
RGB
-
LED Type::
-
5050 0.5W RGB 3in1 LEDs
-
LED Count::
-
480
-
LED Colors::
-
RGB
-
LED Segments::
-
Pixel Mapping
-
Size::
-
58*36*19cm/22.85*14.17*7.48in (carton)
-
Weight::
-
10KG/22.04LB (carton)
Quick Details
-
Color Temperature(CCT):
-
6000K (Daylight Alert)
-
Type:
-
Ground Row Lights
-
Application:
-
Theme Park
-
Warranty(Year):
-
1-Year
-
Lamp Luminous Efficiency(lm/w):
-
1800
-
Color Rendering Index(Ra):
-
85
-
Product Weight（kg）:
-
10
-
Input Voltage(V):
-
AC120V/230V, 60/50Hz
-
Lamp Luminous Flux(lm):
-
100
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-15 - 45
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Grace
-
Emitting Color:
-
RGB
-
LED Type::
-
5050 0.5W RGB 3in1 LEDs
-
LED Count::
-
480
-
LED Colors::
-
RGB
-
LED Segments::
-
Pixel Mapping
-
Size::
-
58*36*19cm/22.85*14.17*7.48in (carton)
-
Weight::
-
10KG/22.04LB (carton)
Technican Specification
|
Strobe Panel LEDs
|
|
|
|
LED Type:
|
5050 0.5W RGB 3in1 LEDs
|
|
|
LED Count:
|
480
|
|
|
LED Colors:
|
RGB
|
|
|
LED Segments:
|
Pixel Mapping
|
|
|
Strobe Tube LEDs
|
|
|
|
LED Type:
|
3535 5W LEDs
|
|
|
LED Count:
|
144
|
|
|
LED Colors:
|
Cool-White+Amber
|
|
|
LED Segments:
|
8+8
|
|
|
Movement
|
|
|
|
Resolution:
|
8-16 Bit
|
|
|
Tilt (Degrees):
|
185°
|
|
|
Control
|
|
|
|
Control Modes:
|
10CH / 20CH / 25CH (Artnet/SACN and DMX mixed mode)
|
|
|
Madrix mode
|
|
|
|
Display:
|
Illuminated graphic LCD
|
|
|
Protocol:
|
USITT DMX-512, RDM, Artnet, SACN
|
|
|
RDM:
|
Bidirectional communication
|
|
|
Cooling:
|
Temperature controlled, overheating protection
|
|
|
Effects
|
|
|
|
Dimmer:
|
0-100% electronic
|
|
|
Shutter:
|
electronic, max. 20 Hz
|
|
|
Internal Effects:
|
LED Macro Effects
|
|
|
Connectors
|
|
|
|
Signal connection:
|
XLR 5-Pin or 3-Pin In&Out
|
|
|
Artnet/SACN connection:
|
RJ45 In&Out
|
|
|
Power Input:
|
PowerCON In&Out
|
|
|
Operating Conditions
|
|
|
|
Mains voltage:
|
100-240V AC / 50-60Hz
|
|
|
Power:
|
1000W
|
|
|
Maximum ambient temperature:
|
-30°C / 86°F, 50°C / 122°F
|
|
|
Operating Position:
|
any
|
|
|
Mounting Options
|
|
|
|
Hanging:
|
Omega-Bracket
|
|
|
Safety wire attachment:
|
foldout eyelets
|
|
|
Shipping
|
|
|
|
Single fixture:
|
cardboard
|
|
|
Tourpack:
|
4-way Flight Case
|
|
|
Housing Colors
|
|
|
|
Standard colors:
|
black
|
|
|
Weight & Size
|
|
|
|
Size:
|
58x36x19cm /22.83×14.17×7.48in(carton)，94x50x49cm (4in1 flight case)
|
|
|
Weight:
|
10KG/22.04LB (carton)
|
|
|
G.W.:
|
57KG/125.66LB (4in1 flight case)
|
|
