Leeboo hot selling electronic equipment Compression anti vibration damper free standing floor mount spring vibration isolator

Leeboo hot selling electronic equipment Compression anti vibration damper free standing floor mount spring vibration isolator

FOB Reference Price: Get Latest Price

≥1 Sets

US $8.3

≥100 Sets

US $7.1

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Product name:: Free standing anti vibration damper spring vibration isolator mount

Size:: Customized Size

Color:: Customized Color

Usage:: Air Conditioning Terminal

Certificate:: ISO9001

Package:: Cartons,Wooden Case,etc

Place of origin:: Henan,China

Surface treatment:: Baking paint

MOQ:: 1

Delivery time:: Within 7 days

Quick Details

Place of Origin:: Henan, China

Brand Name:: LEEBOO

Model Number:: zta

Product name:: Free standing anti vibration damper spring vibration isolator mount

Size:: Customized Size

Color:: Customized Color

Usage:: Air Conditioning Terminal

Certificate:: ISO9001

Package:: Cartons,Wooden Case,etc

Place of origin:: Henan,China

Surface treatment:: Baking paint

MOQ:: 1

Delivery time:: Within 7 days

Product Description

China factory price free standing anti vibration damper spring vibration isolator mount

1. The shell is made of die-cast aluminum alloy material. Compared with the traditional steel iron plate shell, it is beautiful, light in weight and has no rust phenomenon, so it is more durable.
2. This product overcomes the resonance phenomenon that tends to occur when its damping ratio is small. It can ensure that the seismic isolation rate does not decrease when the damping ratio is increased to 0.15-0.18. This is a major breakthrough in the design of steel spring vibration reduction in China in recent years, and it is in the leading position of similar products.

3. Low frequency adjustable shock absorber can be selected according to your different needs.

Normal work temperature -30℃~100℃, Natural frequency 1.8Hz-3.6Hz, Damping ratio 0.04~0.066.

The main purpose:

Applicable to power rotary machinery such as water pumps, fans, compressors, generators, air conditioners, ice water units, cooling water towers, etc.

Technical parameter

Model	load range	Elasticity coefficient	Applicable deflection	Dimensions
ZTA-12	9~17	0.8	15	70	76	75	90	12	8*14
ZTA-18	12~22	1.2	15	70	76	75	90	12	8*14
ZTA-30	18~42	2	15	70	76	75	90	12	8*14
ZTA-40	26~52	2.8	15	70	76	75	90	12	8*14
ZTA-55	34~68	3.6	15	70	76	75	90	12	8*14
ZTA-80	54~105	4.8	20	110	103	100	120	12	10*14
ZTA-120	80~156	6	20	110	103	100	120	12	10*14
ZTA-160	115~218	7.2	20	110	103	100	120	12	10*14
ZTA-240	160~310	12	20	110	103	100	120	12	10*14
ZTA-320	215~422	12	25	140	140	135	165	14	12*23
ZTA-480	295~575	20	25	140	140	135	165	14	12*23
ZTA-640	417~830	24	25	140	140	135	165	14	12*23
ZTA-820	530~1055	34	25	150	205	192	240	16	14*21
ZTA-1000	605~1250	40	25	150	205	192	240	16	14*21
ZTA-1280	830~1650	40	25	150	205	192	240	16	14*21
ZTA-1500	850~1950	64	25	150	205	192	240	16	14*21
ZTA-2000	1000~2800	80	25	150	205	192	240	16	14*21
ZTA-2700	1300~3000	112	25	150	280	235	280	20	16
ZTA-3500	1500~4000	128	25	150	280	235	280	20	16

Packing & Delivery

Packing: Inner plastic film，outer wooden box.
Shipping: by express,by air or by sea.
Shipping port: Shangahi, Qingdao, Tianjin or according to your needs.
Shipping time: 5-15 days after receiving 30% down payment,or according to your needs.
