Quick Details
-
Brand Name:
-
The Nile
-
Voltage:
-
380v
-
Dimension(L*W*H):
-
5104*2713*3106mm
-
Weight:
-
6.5 KG
-
Max. feed size:
-
400mm
-
Capacity:
-
45-280t/h
-
Screen specification:
-
1500*4800mm
-
Mesh size:
-
2-50mm
-
Layer(s):
-
3 Layers
-
Screen slope:
-
15-20°
-
Frequency:
-
970r/min
-
Double amplitude:
-
8
-
OEM:
-
yes
-
Certification:
-
ISO, CE
Quick Details
-
Type:
-
Circular
-
Marketing Type:
-
Hot Product
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
The Nile
-
Voltage:
-
380v
-
Dimension(L*W*H):
-
5104*2713*3106mm
-
Weight:
-
6.5 KG
-
Max. feed size:
-
400mm
-
Capacity:
-
45-280t/h
-
Screen specification:
-
1500*4800mm
-
Mesh size:
-
2-50mm
-
Layer(s):
-
3 Layers
-
Screen slope:
-
15-20°
-
Frequency:
-
970r/min
-
Double amplitude:
-
8
-
OEM:
-
yes
-
Certification:
-
ISO, CE
Stone Vibrating Screening Machine Circular Vibration Screen
The vibration screen trajectory movement of the circular elliptical. It is a multi-layer, high-efficiency new type vibrating screen designed specifically for quarry screening stones. Widely used in mining, coal, smelting, building materials, refractories, light industry, chemical and other industries of product classification.
Working Principle
The round vibrating screen machine produced by the Nile mainly consists of a screen box, a screen, a vibrator, a vibration absorber spring device, a chassis and so on. The vibrator is installed on the side plate of the screen box, and the motor rotates through the triangle belt to produce the centrifugal inertial force and force the vibration of the screen box. The side plate of the screen machine is made of high quality steel plate, and the side plate is connected with the beam and the base of the exciter with high strength bolts or rivets of ring groove. The vibrator is mounted on the side plate of the screen box and rotated by the motor through the coupling to produce centrifugal inertia force, forcing the screen to vibrate.
| Model |
Screen mesh (mm) |
Feed Size (mm) |
Capacity (t/h) |
Motor Power (kw) |
Screen size (m) |
Dimension (m) |
Weight (t) |
| 1YK1237 | 2-50 | 200 | 25-160 | 11 | 1.2*3.7 | 3.9*2.4*2.4 | 4.8 |
| 2YK1237 | 200 | 25-160 | 11 | 1.2*3.7 | 3.9*2.4*2.4 | 4.9 | |
| 3YK1237 | 400 | 30-180 | 11 | 1.2*3.7 | 4.0*2.4*2.9 | 5.2 | |
| 4YK1237 | 400 | 30-180 | 11 | 1.2*3.7 | 4.3*2.4*2.9 | 5.3 | |
| 1YK1548 | 200 | 45-250 | 15 | 1.5*4.8 | 4.9*2.7*2.9 | 5.9 | |
| 2YK1548 | 200 | 45-250 | 15 | 1.5*4.8 | 4.9*2.7*2.9 | 6.3 | |
| 3YK1548 | 400 | 45-280 | 15 | 1.5*4.8 | 5.1*2.7*3.1 | 6.5 | |
| 4YK1548 | 400 | 45-280 | 18.5 | 1.5*4.8 | 5.3*2.7*3.4 | 6.6 | |
| 1YK1848 | 200 | 55-330 | 15 | 1.8*4.8 | 4.9*3.0*2.9 | 6.2 | |
| 2YK1848 | 200 | 55-330 | 15 | 1.8*4.8 | 4.9*3.0*2.9 | 6.9 | |
| 3YK1848 | 400 | 55-350 | 22 | 1.8*4.8 | 5.1*3.0*3.1 | 7.2 | |
| 4YK1848 | 400 | 55-350 | 22 | 1.8*4.8 | 5.3*3.0*3.4 | 7.5 |
Main features:
1.Stable performance and high screening efficiency
The circular vibrating screen follows the structural design of the classic screening equipment, and its performance is fully guaranteed
2.A variety of screens to choose from
To meet the requirements of various classification operations after coarse crushing and medium crushing in the crushing process, we have configured a variety of screens for the circular vibrating screen. So that we can meet different production needs through simple screen replacement operations.
Standard package in wooden boxes or containers.
Bare main machine, motors and small parts are packed in wooden cases. We can also pack them according to your requirement.
