Quick Details
-
Dimensions(L*W*H):
-
4800*1800*2400mm
-
Weight:
-
4500 KG
-
printing colors:
-
4 colors
-
Model number:
-
WQ-RY4600
-
Printing width:
-
600/800/1000/1200mm
-
Printing length:
-
191-1200mm
-
Printing speed:
-
80-100m/min
-
Thickness of plate:
-
2.28mm
-
Dimension of machinery:
-
4800*1800*2400mm
-
printing materials:
-
nonwoven ,paper ,film ,plastic
-
Minimum Order Quantity:
-
1 Set
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ZD
-
Voltage:
-
220V/380V
-
Dimensions(L*W*H):
-
4800*1800*2400mm
-
Weight:
-
4500 KG
-
printing colors:
-
4 colors
-
Model number:
-
WQ-RY4600
-
Printing width:
-
600/800/1000/1200mm
-
Printing length:
-
191-1200mm
-
Printing speed:
-
80-100m/min
-
Thickness of plate:
-
2.28mm
-
Dimension of machinery:
-
4800*1800*2400mm
-
printing materials:
-
nonwoven ,paper ,film ,plastic
-
Minimum Order Quantity:
-
1 Set
Product Description
|
Type
|
Max. width of printing material (mm)
|
Max. width of printing roll(mm)
|
Max.printing width(mm)
|
Printing length(mm)
|
Max. printing colors
|
Gross power(kw)
|
|
ZD-RY2800B
|
1200
|
800
|
700
|
230-1200
|
2
|
10
|
|
ZD-RY4800B
|
1200
|
800
|
700
|
230-1200
|
4
|
12
|
|
ZD-RY6800B
|
1200
|
800
|
700
|
230-1200
|
6
|
15
|
|
ZD-RY8800B
|
1200
|
800
|
700
|
230-1200
|
8
|
18
|
PRODUCT INTRODUCTION:
1. The flexo printing equipment is convenient for operation, and offers soft start and accurate color registration.
2. This flexo printing machine is manufactured with a meter counter. So, it allows users to preset the printing length. When printing length reaches preset value, the printer will automatically stop working. When there is material shortage, the printer will also stop working.
3. Printing cylinder can be either manually or automatically elevated. After the printing cylinder is lifted, the printing machine will automatically stir the printing ink to prevent ink drying.
4. Anilox roller is utilized to ensure uniform and even ink transmission. So the flexo printing machine offers fine printing quality.
5. The flexo printing machine has a reliable drying system and offers high speed operation. It turns off the power supply once it stops working.
6. This printer has a longitudinal register device that is 360 degrees adjustable.
7. With a variable frequency motor for speed control, the flexo printing equipment can meet customers' varied printing speed demands.
8. Touch Control Button and Stop Button are both available on the printing machine's roller base and material rewinding unit, which ensures convenient equipment control while installing the printing plates.
1. Q:How long will your engineer reach our factory?
A:Within one week after everything ready (machine arrival your factory, nonwoven material, power source, air compressor etc.Prepared).
2. Q:How many days will you finish installing ?
A:We will finish installation and training within 15 days.
3. Q:What should we charge for your engineer?
A:You should charge for the cost of our engineer's air tickets, hotel, food, and also their salary 80USD one day per person.
4. Q:How long is your machine's warranty period?
A: All our machine have half a years guarantee for electricity parts and one years guarantee for mechanism, starting from finished installation.
5. Q:How could you do if the parts broken within warranty?
A: We would express the free replacement parts during the warranty date.
6. Q:How could you do after one year warranty period?
A:We also can do service for you, but you need pay salary for our technicians 80USD/day for each person.
7. Q:Does your engineer understand English?
A:Our engineers understand a little English. All our engineers have more than five years machine installation experience.
8. Q:Can you help us find any engineer in our location?
A:Of course, we will check and inform you as soon as possible.
9. Q:How do we solve the machine problem after your engineer leaving?
A:Generally speaking, there will be no problem after finishing installation. In case you have any problem, you can contact our sales at any time. Our engineers will take a solution video according your description.
2. Q:How many days will you finish installing ?
A:We will finish installation and training within 15 days.
3. Q:What should we charge for your engineer?
A:You should charge for the cost of our engineer's air tickets, hotel, food, and also their salary 80USD one day per person.
4. Q:How long is your machine's warranty period?
A: All our machine have half a years guarantee for electricity parts and one years guarantee for mechanism, starting from finished installation.
5. Q:How could you do if the parts broken within warranty?
A: We would express the free replacement parts during the warranty date.
6. Q:How could you do after one year warranty period?
A:We also can do service for you, but you need pay salary for our technicians 80USD/day for each person.
7. Q:Does your engineer understand English?
A:Our engineers understand a little English. All our engineers have more than five years machine installation experience.
8. Q:Can you help us find any engineer in our location?
A:Of course, we will check and inform you as soon as possible.
9. Q:How do we solve the machine problem after your engineer leaving?
A:Generally speaking, there will be no problem after finishing installation. In case you have any problem, you can contact our sales at any time. Our engineers will take a solution video according your description.
