Easy Installation Spring Vibration Isolator HVAC Mounts Spring Mount Industrial Shock Absorber

Easy Installation Spring Vibration Isolator HVAC Mounts Spring Mount Industrial Shock Absorber

FOB Reference Price: Get Latest Price

≥10 Pieces

US $2

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Product name:: Anti Vibration Spring Mounts

Material:: Galvanized Steel

Load capacity:: 10~1000kg

Certificate:: ISO9001

Function:: Vibration Attenuation

Installation:: Floor Standing

Rated Deflection:: 25mm

Spring Rate:: 4~20kg/mm

OEM:: Valid

Quick Details

Place of Origin:: Jiangsu, China

Brand Name:: Bellking

Model Number:: MD/MDF

Product name:: Anti Vibration Spring Mounts

Material:: Galvanized Steel

Load capacity:: 10~1000kg

Certificate:: ISO9001

Function:: Vibration Attenuation

Installation:: Floor Standing

Rated Deflection:: 25mm

Spring Rate:: 4~20kg/mm

OEM:: Valid

Product Description

CHARACTERISTICS

* Mainly used with an inertial base as an open-type spring mount.

* Easy to install, allows easy inspection since the spring.

* Deflection can be visually checked.

* With a spring deflection of 25mm~50mm.

*Usd for equipment that needs maximum isolation.

BENEFITS

- Quick and easy installation

- Heavy-duty vibration isolation

APPLICATION

- Air conditioning, exhaust fan

- Chillers, Water cooling tower

- Genset, Pump

- Isolation base

- Pumps concrete base

Size Information

Spec	Dimensions(mm)
Spec		L	W	A	H	φD	Mounting Bolt
MD	145	80	120	160	77	M12
MDF	120	120	/	200	104	M12

Type	Rated Capacity(kg)	Spring Rate (kg/mm)	Rated Deflection (mm)	Color Code
MD-100	90-105	4.2	25	Yellow
MD-200	160-210	7.6	25	Green
MD-300	260-320	11.4	25	Red
MD-400	360-430	15.2	25	Blue
MD-500	470-530	19.2	25	Brown
MD-600	530-650	22.8	25	Gray
MD-700	650-700	26.6	25	White
MD-850	700-850	33.6	25	Khaki
MD-1000	860-1000	38	25	Blackish green
MDF-100	90-120	1.8	50	Yellow
MDF-200	190-230	3.8	50	Green
MDF-300	280-320	5.7	50	Red
MDF-400	370-420	7.6	50	Blue
MDF-500	480-520	9.5	50	Brown
MDF-600	520-610	11.4	50	Gray
MDF-700	680-720	13.3	50	White
MDF-850	810-870	16.2	50	Khaki
MDF-1000	870-1080	19.6	50	Blackish green

Application

Related Products

Packing&Shipping

Packing: Cartons & Wooden cases

Shipping: Door-to-Door Air Freight & FOB & CFR

After Sales Service

1.Free one-year warranty. Goods received within 15days of quality problems can be returned for replacement.

2. Provided the product instruction manual. The installation method can be guided on line.

3. The professional technicians shall make shock absorption scheme according to the actual situation on the spot.
