Quick Details
-
Final product:
-
yarn cylinder
-
Price:
-
contact for details
-
Place:
-
Zhanjing
-
Yarn size:
-
150-600/kg
-
power:
-
1.5kw
-
Dimension:
-
920*700*1000mm
-
capacity:
-
200-300kg/shift
-
keyword:
-
yarn winding machine
-
Certification:
-
WEIDA QC
Quick Details
-
Place of Origin:
-
Guangdong, China
-
After-sales Service Provided:
-
Video technical support, Online support, Engineers available to service machinery overseas
-
Raw material:
-
plant fiber
-
Final product:
-
yarn cylinder
-
Price:
-
contact for details
-
Place:
-
Zhanjing
-
Yarn size:
-
150-600/kg
-
power:
-
1.5kw
-
Dimension:
-
920*700*1000mm
-
capacity:
-
200-300kg/shift
-
keyword:
-
yarn winding machine
-
Certification:
-
WEIDA QC
Work Principle:
The power is transmitted to the cam, which drives the winding fork to have rectilinear motion. The yarns are winded evenly on the main shaft with the V shape on the surface. It enables the yarn column keep tight and be in shape even without bobbin.
Function:
This is an advanced and useful plant fiber yarn winding machine. It is mainly used in winding the yarns of different sizes to standard yarn cylinder which is compact and tight, good looking and easy for transportation. This yarn winding machine is a professional machine for yarn winding with the features of good structure, easy to operate and high efficiency.
Main technical data:
| Model | DL-250 | DL-250A | DL-200 |
| Yarn Size | 150-600m/kg | 150-600m/kg | 120-480m/kg |
| Power | 1.5kw | 1.5kw | 1.5kw |
| Dimension | 920×700×1000mm | 920×700×1300mm | 920×700×1000mm |
| Prodution Capacity | 200-300kg/shift | 200-300kg/shift |
200-300kg/shift
|
