Quick Details
-
Place of Origin:
-
henan,China
-
Brand Name:
-
lunyee
-
Model Number:
-
L4D40-12
-
Torque:
-
high
-
Product name:
-
DC PM Motor
-
color:
-
black
-
power:
-
40W
-
Noise:
-
low
-
Diameter:
-
80mm
-
Motor type:
-
brushless/brushed
-
Gear Material:
-
metal
-
Material:
-
metal
Quick Details
-
Speed(RPM):
-
2800r/min
-
Continuous Current(A):
-
≤5.2A
-
Efficiency:
-
40W
-
Place of Origin:
-
henan,China
-
Brand Name:
-
lunyee
-
Model Number:
-
L4D40-12
-
Torque:
-
high
-
Product name:
-
DC PM Motor
-
color:
-
black
-
power:
-
40W
-
Noise:
-
low
-
Diameter:
-
80mm
-
Motor type:
-
brushless/brushed
-
Gear Material:
-
metal
-
Material:
-
metal
Wholesale 12 V 24 VOLT Small Battery Powered Vibration Brush Motors Micro DC mini Fan motor
Production Description for dc gear motor
Here are some detailed pictures of our
Wholesale 12 V 24 VOLT Small Battery Powered Vibration Brush Motors Micro DC mini Fan motor
. Please contact me feeling free if you want to to know more information.
Parameters for dc gear motor
Below table is the parameters of the
Wholesale 12 V 24 VOLT Small Battery Powered Vibration Brush Motors Micro DC mini Fan motor
.You can look at it carefully or ask me to learn more about it.
|
40W 80mm DC Motor
|
|
|
|
|
|
|
|
|
|
|||||||||
|
Model
|
Voltage
|
|
No-load Parameters
|
|
Load Parameters
|
|
|
|
|
|||||||||
|
|
|
|
Speed
|
Current
|
Speed
|
Torque
|
Current
|
|
|
|||||||||
|
|
V
|
W
|
r/min
|
A
|
r/min
|
mN.m
|
A
|
H
|
kg
|
|||||||||
|
L4D40-12
|
12
|
40
|
3100
|
2.0Max
|
2800
|
136
|
5.2
|
2000
|
1.8
|
|||||||||
|
L4D40-24
|
24
|
40
|
3100
|
0.8Max
|
3000
|
127
|
2.1
|
2000
|
1.8
|
|||||||||
|
L4D40-90
|
90
|
40
|
3200
|
0.3Max
|
3000
|
127
|
0.7
|
2000
|
1.8
|
|||||||||
Motor voltage,power and speed will be customized according to his requestment under the allowed circumstance of adoptable dimension
Dimensions for dc gear motor
Below are some important dimensions for the
Wholesale 12 V 24 VOLT Small Battery Powered Vibration Brush Motors Micro DC mini Fan motor
.if you want to make some small chnages on some part of them,please contact me. I will offer you a good idea and choice.
Shaft Section Of Round Shaft Type
Excluding weight and the shaft section motor shape are the same as those of the pinion shaft type.
Lead Wirng Type
Weight: Motor:1.8kg Gearhead: 0.8kg
Mounting screws are included with gearhead.
Wiring Diagrm Of Motor
Stanclard length of lead wire:300mm±10,model:UI1015;type:AWG16;lead wire length,model will be customized by client requestment
under allowed circumstance of adoptable dimension.
under allowed circumstance of adoptable dimension.
Application of dc gear motor
These
Wholesale 12 V 24 VOLT Small Battery Powered Vibration Brush Motors Micro DC mini Fan motor
can also be applied in other different fields. Below picture shows some of them,including building lobby,stadium,factory,mall/surpermarket,club, amusement park,metro part and so on.
Products except dc gear motor
Below is a gross table for common DC motors
parameters range we can offer
.We can offer customized motors with other parameters because we have our own factory. Looking forward to receive your inquiry.
|
Common motors parameters range we can offer
|
|
|
|
Voltage
|
12V~220V
|
|
|
Current
|
0.8A~16.0A
|
|
|
Power
|
6W~750W
|
|
|
Gear Ratio
|
3~200
|
|
|
Diameters
|
60mm~104mm
|
|
|
Torque
|
19mN.m~796mN.m
|
|
|
This form cannot contain all products from our company. If you want other kinds motors you can send me your requirements. We will offer you the best answer.
|
|
|
Package for dc gear motor
Our company use something like below to package our
Wholesale 12 V 24 VOLT Small Battery Powered Vibration Brush Motors Micro DC mini Fan motor
to make sure that our clients can be satisfied with our services .
1.Inside :Plastic bags with Chemical Desiccant For Gear Housing.
2.Middle :Individual Carton packaging
3. Outside :Wooden Box
FAQ
|
1. Q: What's type of your company?
|
|
A: We are manufacturer.
|
|
2. Q: what should I provide when I choose BLDC MOTOR?
|
|
A: 1) load condition
|
|
2) speed of rotation or speed ratio(combination with combine speed reducer can get extra low out putting rotational speed)
|
|
3) work circumstance(temperature, humidity,corrosion etc.)
|
|
4) space of installation
|
|
3. Q: How long dose it take to finish my order?
|
|
A: It depends on your quantity.
|
|
4. Q: How can i know the process of my order?
|
|
A: Detailed picture of the production process will be sent to you to confirm before shipping.
Consummation QC system makes it possible to offer you reliable quality
|
|
5. Q: When is the best time to contact you?
|
|
A: Any time,7 days,24 hours constantly on duty.Contact us: sales002 @lunyee.net ,P:86-13223091060
|
