- Product Details
- {{item.text}}
Quick Details
-
Engine:
-
Single Cylinder
-
Transmission:
-
Auto Cluch Chain Drive
-
Brake:
-
Rear Disc Brake
-
Piston displacement:
-
50cc/110cc/125cc
-
MAX SPEED:
-
65km/h
-
Wheel size:
-
19*7-8/18*9.5-8
-
Max power:
-
3.0Kw/8500rpm
-
Front suspension detail:
-
Double
-
Color available:
-
Red. Blue Orange Black
Quick Details
-
Displacement:
-
110cc
-
Brand Name:
-
Jinling
-
Place of Origin:
-
Zhejiang, China
-
Engine:
-
Single Cylinder
-
Transmission:
-
Auto Cluch Chain Drive
-
Brake:
-
Rear Disc Brake
-
Piston displacement:
-
50cc/110cc/125cc
-
MAX SPEED:
-
65km/h
-
Wheel size:
-
19*7-8/18*9.5-8
-
Max power:
-
3.0Kw/8500rpm
-
Front suspension detail:
-
Double
-
Color available:
-
Red. Blue Orange Black
Recommend Products
Product Description
|
1.Model No.
|
JLA-07-06-8A-125
|
|
2.Warranty
|
one year for engine, 6months for other parts
|
|
3.Approval
|
CE
|
|
ENGINE
|
|
|
4.Cylinder
|
Single
|
|
5.Cooled System
|
Air
|
|
6.Engine Stroke
|
4 Stroke
|
|
7.Bore*Stroke(mm)
|
55.5X49.5mm
|
|
8.Displacement(ml)
|
125cc
|
|
9.Max.power(kw/rpm)
|
6.8kw/7500rpm
|
|
10.Max.torque(n.m/rpm)
|
8.6Nm/5000rpm
|
|
11.Ignition Type
|
CDI
|
|
TRANSMISSION
|
|
|
12.Transmission Type
|
Automatic,chain
|
|
13.Primary Drive(Rear Wheel)
|
Chain 4x2
|
|
14.Reverse
|
No
|
|
15.Max Speed(km/h)
|
≥50
|
|
WHEEL
|
|
|
16.Front wheel
|
19X7-8
|
|
17.Rear wheel
|
18X9.5-8
|
|
SUSPENSION
|
|
|
18.Front Suspension
|
Double A-Swing Arm
|
|
19.Rear Suspension
|
Mono Shock Swing Arm
|
|
BRAKE SYSTEM
|
|
|
20.Front brake
|
Drum
|
|
21.Rear brake
|
Disc
|
|
22.Braking distance
|
8m(30km/h)
|
|
TECHINCAL SPECIFICATIONS
|
|
|
23.Product Dimensions(mm)
|
1410x1000x900mm
|
|
24.Ground Clearance(mm)
|
100mm
|
|
25.Wheelbase(mm)
|
950mm
|
|
26.Mini Turning Radius(mm)
|
2800mm
|
|
27.Gross weight(kgs)
|
116
|
|
28.Net weight(kgs)
|
108
|
|
29.Fuel Capacity(L)
|
3.2
|
|
30.Fuel consumption
|
3.0L/100KM
|
|
SEAT
|
|
|
31.Seat Height(mm)
|
620
|
|
32.Number of Seats
|
1
|
|
COLOR
|
|
|
33.Standard Color
|
Red/Yellow/Blue/Green/Black/White
|
|
34.Optional Color
|
Green camo,Yellow camo,Snow Camo,Metallic,Carbon
|
|
LOADING
|
|
|
35.Packing Size(mm)
|
1310x840x660 (Steel frame inside,carton outside)
|
|
36.Quantity
|
20FT:34PCS; 40FT:69PCS; 40HQ:92PCS
|
|
PRICE
|
|
|
37.MOQ
|
1X20FT
|
