High working efficiency.
Less water consumption.
Cleaning bottle thoroughly.
Simple operation.
Large bottle application.
Less water consumption.
Cleaning bottle thoroughly.
Simple operation.
Large bottle application.
- Product Details
- {{item.text}}
Quick Details
-
Filling Accuracy:
-
±1.5ml
-
Voltage:
-
customized
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
TONGDA
-
Dimension(L*W*H):
-
1550*1430*1900mm
-
Weight:
-
600 KG
-
rinsing application:
-
glass bottle
-
rinsing heads number:
-
16
-
rinsing speed:
-
2000-3000bph
-
rinsing method:
-
water rinsing
-
rinsing range:
-
inside rinsing and outside rinsing
-
bottles height:
-
100-320mm
-
max bottles diameter:
-
119mm
-
materials:
-
ss304/316
-
function:
-
cleaning bottles inner and outside
-
warranty:
-
12months
Quick Details
-
Machinery Capacity:
-
8000BPH, 12000BPH, 6000BPH, 400BPH, 20000BPH, 16000BPH, 2000BPH
-
Packaging Material:
-
Plastic, Glass
-
Filling Material:
-
Water, Juice, spirits
-
Filling Accuracy:
-
±1.5ml
-
Voltage:
-
customized
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
TONGDA
-
Dimension(L*W*H):
-
1550*1430*1900mm
-
Weight:
-
600 KG
-
rinsing application:
-
glass bottle
-
rinsing heads number:
-
16
-
rinsing speed:
-
2000-3000bph
-
rinsing method:
-
water rinsing
-
rinsing range:
-
inside rinsing and outside rinsing
-
bottles height:
-
100-320mm
-
max bottles diameter:
-
119mm
-
materials:
-
ss304/316
-
function:
-
cleaning bottles inner and outside
-
warranty:
-
12months
Products Description
|
Model
|
heads quatities
|
max capability(BPH)
|
power
|
applicated bottle height
|
diameter
|
water consumption
|
|
GCP-16
|
16
|
3000
|
1.5
|
100-360
|
25-100
|
0.7
|
|
GCP-18
|
18
|
3000-4000
|
2
|
100-360
|
25-100
|
2.1
|
|
GCP-24
|
24
|
5000-6000
|
2.85
|
100-360
|
25-100
|
2.6
|
|
GCP-30
|
30
|
7000-9000
|
3.6
|
100-360
|
25-100
|
3
|
|
GCP-48
|
48
|
10000-12000
|
4.8
|
100-360
|
25-100
|
3.6
|
|
GCP-60
|
60
|
12000-15000
|
6.5
|
100-360
|
25-100
|
4.5
|
Product Information
bottles washing machine body
Fast bottle washing.
positioning clip
To clamp bottle mouth tightly.
No damage bottle.
Food grade material.
Bottle Feeding-in Screw and Starwheels
To keep bottles move freely and smoothly. High quality material
no damage the bottles.
Glass housing protection
Tempered glass for protection.
High quality hinge for tight connection
Top View for the rinser
Bottle feeding into the rinser by screw asn starwheels.
Bottle to be cleaned by water inside and outside.
There are bottle washing zone and bottle drain zone.
There are bottle washing zone and bottle drain zone.
