Quick Details
-
Color:
-
FULL COLOR
-
Panel Size:
-
320*160mm
-
Place of Origin:
-
Henan, China
-
Model Number:
-
FL4
-
Name:
-
Indoor Flexible Circle Panel 360 Degree P2 Roll-Up Display Screen
-
Brightness:
-
1000nits
-
LED chip:
-
SMD
-
Viewing angle:
-
160/160degree
-
Cabinet material:
-
Die-casting Aluminum
-
Software:
-
LED Studio
-
Cabinet size:
-
Customized
-
Display function:
-
Video
-
Warranty:
-
5 Years
Quick Details
-
Application:
-
Indoor, Cylindrical Column Use
-
Type:
-
LED
-
Brand Name:
-
CANBEST
-
Color:
-
FULL COLOR
-
Panel Size:
-
320*160mm
-
Place of Origin:
-
Henan, China
-
Model Number:
-
FL4
-
Name:
-
Indoor Flexible Circle Panel 360 Degree P2 Roll-Up Display Screen
-
Brightness:
-
1000nits
-
LED chip:
-
SMD
-
Viewing angle:
-
160/160degree
-
Cabinet material:
-
Die-casting Aluminum
-
Software:
-
LED Studio
-
Cabinet size:
-
Customized
-
Display function:
-
Video
-
Warranty:
-
5 Years
Warranty
Product Description
Technical Parameters
|
Model
|
FL2
|
|
Pixel Pitch(mm)
|
2.5
|
|
Module Size(mm*mm)
|
240*120*8
|
|
Module number per Sq.m
|
34.7
|
|
LED Type
|
Kinglight SMD2121
|
|
Cabinet Size(mm*mm*mm)
|
Customized
|
|
Module Resolution (pixel*pixel)
|
96*48
|
|
Model Weight( Kg)
|
0.17
|
|
Horizontal Viewing Angle(Deg)
|
160
|
|
Vertical Viewing Angle(Deg)
|
140
|
|
Brightness
|
1200
|
|
Scanning Mode
|
1/24
|
|
Driving IC
|
MBI5124
|
|
Gray Scale(bit)
|
16
|
|
Refresh Rate(Hz)
|
1920
|
|
Max Power Consumption(W/sqm)
|
710
|
|
Average Power Consumption(W/sqm)
|
250
|
|
Input Voltage(V)
|
200~240
|
|
Ingress Protection
|
IP43
|
