Quick Details
-
Climbing Ability:
-
<20%
-
Mini Turning Radius:
-
3.5m
-
Min.Clearance:
-
105mm
-
Recharge Time:
-
8-10hours
-
L*W*H:
-
2375*1206*1920mm
-
F/R Tread:
-
855/980mm
Quick Details
-
Passenger Capacity:
-
4 Seats
-
Max.Speed:
-
25-30km/h(adjustable)
-
Driving Range:
-
80km
-
Climbing Ability:
-
<20%
-
Mini Turning Radius:
-
3.5m
-
Min.Clearance:
-
105mm
-
Recharge Time:
-
8-10hours
-
L*W*H:
-
2375*1206*1920mm
-
F/R Tread:
-
855/980mm
Products Description
The power of the golf cart redefines the national car,
The outstanding appearance and outstanding driving and riding feeling into one.
An environmentally friendly passenger vehicle designed and developed for golf courses.
It can also be used in resorts, villas, garden hotels, tourist attractions, etc.
From golf courses, villas, hotels, schools and private users, there will be short trips.
Interior decoration, such as Scottish bagpipes playing the melody, melodious, wonderful, place in the car is safe and comfortable, the heart contains in every detail.
The outstanding appearance and outstanding driving and riding feeling into one.
An environmentally friendly passenger vehicle designed and developed for golf courses.
It can also be used in resorts, villas, garden hotels, tourist attractions, etc.
From golf courses, villas, hotels, schools and private users, there will be short trips.
Interior decoration, such as Scottish bagpipes playing the melody, melodious, wonderful, place in the car is safe and comfortable, the heart contains in every detail.
Product Paramenters
|
Performance
|
|
|
|
Passenger Capacity
|
6 Seats
|
|
|
Max.Speed
|
25-30km/h(adjustable)
|
|
|
Driving Range
|
80km
|
|
|
Climbing Ability
|
<20%
|
|
|
Braking Distance
|
<3.5
|
|
|
Mini Turning Radius
|
6m
|
|
|
Min.Clearance
|
105mm
|
|
|
Recharge Time
|
8-10hours
|
|
|
Dimension
|
|
|
|
L*W*H
|
3880*1209*1920mm
|
|
|
F/R Tread
|
855/980mm
|
|
|
Axle Distance
|
3190mm
|
|
|
Curb Weight
|
620kgs
|
|
|
Standard Configurations
|
|
|
|
Motor
|
ADC Brand 3.8KW Motor (USA brand)
|
|
|
Controller
|
Curtis Controller (48V 275A) (USA brand)
|
|
|
Battery
|
Huge capacity deep cycle lead-acid battery 8V/piece 6 pieces
|
|
|
Body & Roof
|
Injection molding design separable replacement
|
|
|
Windshield
|
Tempered glass with wiper
|
|
|
Seats
|
Sponge&artificial Leather with flexible two-point seat belts + three-point belt
|
|
|
Rear View Mirror
|
2 pcs
|
|
|
Bumper
|
Front and Rear bumper
|
|
|
Tire
|
Golf tyre 22*10-10
|
|
|
Chassis
|
High strength structural steel
|
|
|
Steering
|
Gear Steering, auto Backlash Compensation
|
|
|
Brake System
|
Rear Brake+ Composite Pedal Brake
|
|
|
Front Axle
|
Non Independent Suspension, Leaf Spring + Cylindrical Hydraulic Shock Absorb
|
|
|
Rear Axle
|
Integral Rear Axle, Non Independent Suspension, Spring, Sylinder Type Hydraulic Shock Absorb
|
|
|
Light System
|
Combination front light (turning light, high beam, dipped light) rear lighting (turning light, brake light) driving & reverse
buzzer. |
|
|
Charger
|
On board charger
|
|
|
Dashboard
|
Plastic molding instrument board with volt meter, ammeter,electricity indicator, speedometer,electric key switch, radio with blue
tooth, storage box, cup holder,turn signal indicator,forward and Revise indicator. |
|
Product Features
Unique design * Considerate safety
Covered with "PP" automotive engineering materials, can withstand weighing 40 tons of truck rolling. Ultimate
security,durable,anti-aging with beautiful appearance, long life cycle performance.
Convenient * Low power consumption
Large-capacity battery, energy saving, short charging time. Driving for 100 km with 5 hours' charge.
International standard quality * Advanced configuration
Imported Rear Axle technology, safer and more stable
Practical * Flexible
Multipurpose pedal, set parking, braking, acceleration function together as a whole, easy to operate
Innovative concept * Durable materials
Steel chassis, brackets, strong material, innovative electrophoresis soak on the material inside and outside, enhanced corrosion resistance ability
Innovative choice * Extreme durability
Independent suspension damping system,utilizing car steering system design to reduce changes in beam positioning, double-spring dispersion stress to reduce the sense of vibration, significantly enhance the ride comfort
Intelligent control * travel at heart
Apply imported controller, computer programming a variety of operating modes,in addition with electric brake and automatic anti-charging function
Covered with "PP" automotive engineering materials, can withstand weighing 40 tons of truck rolling. Ultimate
security,durable,anti-aging with beautiful appearance, long life cycle performance.
Convenient * Low power consumption
Large-capacity battery, energy saving, short charging time. Driving for 100 km with 5 hours' charge.
International standard quality * Advanced configuration
Imported Rear Axle technology, safer and more stable
Practical * Flexible
Multipurpose pedal, set parking, braking, acceleration function together as a whole, easy to operate
Innovative concept * Durable materials
Steel chassis, brackets, strong material, innovative electrophoresis soak on the material inside and outside, enhanced corrosion resistance ability
Innovative choice * Extreme durability
Independent suspension damping system,utilizing car steering system design to reduce changes in beam positioning, double-spring dispersion stress to reduce the sense of vibration, significantly enhance the ride comfort
Intelligent control * travel at heart
Apply imported controller, computer programming a variety of operating modes,in addition with electric brake and automatic anti-charging function
Details Images
dashboard
Complete functions, simple and easy to operate
vacuum tire
Vacuum tires anti-skid and wear-resistant, long service life Customizable off-road big wheel (beach wheel)
Comfort seat + seat belt
Beautiful and comfortable, good ventilation, comfortable seat, backrest.
3500w powerful motor
High-power motor, fast speed increase, strong performance, can last 100km
steel structure frame
Strong, durable, stable and elastic, any road surface will be more comfortable
spring shock absorption
Special high-efficiency shock absorption, easy to cross obstacles, reduce bumps, more stable
LED headlamps
Automotive-grade LED headlights nighttime running lights, make your night travel safer
Awning
Beautiful and practical, the overall structure is smooth, convenient for you to travel
custom back seat
Customizable rear seat, custom seat position and color
rear storage space
Larger capacity for easy loading of your items
