- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
RK1-06
-
Max. Current:
-
20A
-
Mechanical Life:
-
10,000 Cycles
-
Function:
-
ON-OFF
-
Operating Temperature:
-
-25-85℃
-
Operation Force:
-
2N-8N
-
Insulation Resistance:
-
100MΩ
-
Contact Resistance:
-
20mΩ
-
Withstand Voltage:
-
1500VAC/min
-
LED Light Color:
-
Amber\Orange\Red\Blue\Green
-
Mechanical Life::
-
10000, 100,000 times
-
Cover Dimensions::
-
48.43X26.48mm
-
Certification:
-
CE
Quick Details
-
Max. Voltage:
-
24V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Liteam
-
Model Number:
-
RK1-06
-
Max. Current:
-
20A
-
Mechanical Life:
-
10,000 Cycles
-
Function:
-
ON-OFF
-
Operating Temperature:
-
-25-85℃
-
Operation Force:
-
2N-8N
-
Insulation Resistance:
-
100MΩ
-
Contact Resistance:
-
20mΩ
-
Withstand Voltage:
-
1500VAC/min
-
LED Light Color:
-
Amber\Orange\Red\Blue\Green
-
Mechanical Life::
-
10000, 100,000 times
-
Cover Dimensions::
-
48.43X26.48mm
-
Certification:
-
CE
Product Description
Summarization
|
Product Name |
Red waterproof 3 pin on-off aA 220V t120/55 rleil rocker switch |
| Rating | 20A 24V |
| Function | ON-OFF |
| Withstand Voltage | ≥1500VAC/5S |
| Button Color | Black+Red |
| Insulation Resistance | ≥100MΩ |
| Contact Resistance | ≤20MΩ |
| Terminal Strength | ≥50N |
| Terminal to Button | ≥2000VAC/5S |
| Mechanical Life | 10,000 Cycles |
| Operation Force | 2N-8N |
| Material | Nylon |
